Configure security settings

Filtering on TCP flags

An ip-object can be followed by an optional [flags] field.

Filters based on any combination of TCP flags. The [flags] field specifies the flags to check and

consists of the flags keyword followed by a string specifying the flags themselves. Each letter in

this string represents a particular flag type as listed below:

These flag codes allow the filter to check any combination of flags.

Following on from the previous example, to block packets that have all the flags set you would need

to precede the pass rule with the following block rule:

block break end from any to 10.1.2.0/24 port=telnet flags frspua

Here, the list of flags causes the router to check that those flags are set. This list may be optionally

followed by an exclamation mark (!) and a second list of flags that the router should check for being

For example. the following [flags] field tests for the s flag being on and the a flag being off with all

other flags ignored.

As a further example, suppose we want to allow outward connections from a machine on 10.1.2.33

to a Telnet server. We have to define a filter rule to pass outbound connections and the inbound

response packets. Because this is an outbound Telnet service we can make use of the fact that all

incoming packets will have their ACK bits set. Only the first packet establishing the connection will

have the ACK bit off. The filter rules to do this would look like this:

pass out break end from 10.1.2.33 port>1023 to any port=telnet

pass in break end from any port=telnet to 10.1.2.33 port>1023 flags !a

The first rule allows the outward connections, and the second rule allows the response packets

back in which the ACK flag must always be on. This second rule will filter out any packets that do not

have the ACK flag on. This will bar any attackers from trying to open connections onto the private

network by simply specifying the source port as the Telnet port. Note that there is a simpler way to

achieve the same effect using the inspect state option, described below.
