Digi TransPort WR11 Quick Start Manual

Quick Start Guide

TransPort® WR11
LTE Models
1 Verify your components
Verify that you have all included equipment. If any item is missing or damaged, contact your supplier.
2 Connect the hardware
1. Open the SIM door. Using your finger, slide the SIM door out and
lift up.
2. Insert the SIM card(s) as shown, with the notch facing the bottom-
right corner of the device. If you are using one SIM card only,
insert it in the SIM 1 slot.
3. Close the SIM door.
Note Position the Digi TransPort WR11 on a flat, level surface in a location with adequate ventilation. The unit is designed for indoor use.
Do not expose the unit to extreme heat or cold, strong magnetic fields, or liquids.
© 2016 Digi International Inc.
Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States and other countries worldwide. All other trademarks mentioned in this
document are the property of their respective owners.
Welcome to your Digi product
Get started: This guide helps you with initial product setup. Need more? Find additional
product support at www.digi.com/support/TransPortWR11. Or connect to the online
documentation by scanning this code:
Digi Technical Support: Digi offers multiple support plans to help you get the most out of
your product. For information on Technical Support plans and pricing, contact us at
877.912.3444 or visit www.digi.com/support.
Documentation Feedback: To provide feedback on this documentation, send your
comments to techcomm@digi.com.
Included equipment
Required additional equipment
Connect the primary and secondary cellular antennas to the
4.
respective antenna connectors on the unit.
Note Two antennas are required for normal operation of this
device.
Connect the plug end of the 5-volt power supply to the power
5.
connector on the unit, and plug the other end into a wall outlet.
Insert the power supply end fully and rotate clockwise to engage
and lock.
Connect one end of the Ethernet cable to the Ethernet port on the
6.
unit and the other end to an Ethernet port on a PC.
