Installation and Basic Configuration Guide
NOTE: A change in the buffer size takes effect only after you restart the system. The buffer size does not
affect how many entries the device can log on a Syslog server. The number of entries the device can log on
the server depends on the server's configuration.
6. Select the messages facility. The default is User. For a list of values, display the pulldown menu.
7. Select the message levels you want the device to log. All the levels are logged by default.
8. Click Apply to save the changes to the device's running-config file.
9. Select the Save link at the bottom of the dialog. Select Yes when prompted to save the configuration change
to the startup-config file on the device's flash memory.
10. To view a list of the Syslog servers that have been defined, click the Show Log Server link under the Apply
and Reset buttons to display the Log Server panel.
Figure 15 List of Log Servers
The list shows the IP Addresses and UDP Ports of the Syslog Servers.
11. To delete an entry, click on the Delete button for that entry.
12. Select the Save link at the bottom of the dialog. Select Yes when prompted to save the configuration change
to the startup-config file on the device's flash memory.
13. To add a Syslog server, click on the Add Log Server link under the dialog to display the System Log Server
panel.
Figure 16 System Log Server Panel
14. Enter the IP address of the new Syslog server, if you want the device to log messages on the Syslog server
as well as in the local buffer.
15. Enter the UDP port on the server that will be used for logging messages.
A - 8
