Configuring Virtual LANs (VLANs)
HP9300A(config-vlan-102)# exit
HP9300A(config)# vlan 103 by port
HP9300A(config-vlan-103)# tagged ethernet 2/1
HP9300A(config-vlan-103)# untagged ethernet 1/3
HP9300A(config-vlan-103)# exit
HP9300A(config)# vlan 104 by port
HP9300A(config-vlan-104)# tagged ethernet 2/1
HP9300A(config-vlan-104)# untagged ethernet 1/4
HP9300A(config-vlan-104)# exit
HP9300A(config)# vlan 105 by port
HP9300A(config-vlan-105)# tagged ethernet 2/1
HP9300A(config-vlan-105)# untagged ethernet 1/5
HP9300A(config-vlan-105)# exit
HP9300A(config)# write memory
Commands for Device B
The commands for configuring device B are identical to the commands for configuring device A. Notice that you
can use the same channel VLAN numbers on each device. The devices that aggregate the VLANs into a path can
distinguish between the identically named channel VLANs based on the ID of the path VLAN.
HP9300B(config)# vlan 101 by port
HP9300B(config-vlan-101)# tagged ethernet 2/1
HP9300B(config-vlan-101)# untagged ethernet 1/1
HP9300B(config-vlan-101)# exit
HP9300B(config)# vlan 102 by port
HP9300B(config-vlan-102)# tagged ethernet 2/1
HP9300B(config-vlan-102)# untagged ethernet 1/2
HP9300B(config-vlan-102)# exit
HP9300B(config)# vlan 103 by port
HP9300B(config-vlan-103)# tagged ethernet 2/1
HP9300B(config-vlan-103)# untagged ethernet 1/3
HP9300B(config-vlan-103)# exit
HP9300B(config)# vlan 104 by port
HP9300B(config-vlan-104)# tagged ethernet 2/1
HP9300B(config-vlan-104)# untagged ethernet 1/4
HP9300B(config-vlan-104)# exit
HP9300B(config)# vlan 105 by port
HP9300B(config-vlan-105)# tagged ethernet 2/1
HP9300B(config-vlan-105)# untagged ethernet 1/5
HP9300B(config-vlan-105)# exit
HP9300B(config)# write memory
Commands for Device C
Since device C is aggregating channel VLANs from devices A and B into a single path, you need to change the
tag type and enable VLAN aggregation.
HP9300C(config)# tag-type 9100
HP9300C(config)# aggregated-vlan
HP9300C(config)# vlan 101 by port
HP9300C(config-vlan-101)# tagged ethernet 4/1
HP9300C(config-vlan-101)# untagged ethernet 3/1
HP9300C(config-vlan-101)# exit
HP9300C(config)# vlan 102 by port
HP9300C(config-vlan-102)# tagged ethernet 4/1
HP9300C(config-vlan-102)# untagged ethernet 3/2
HP9300C(config-vlan-102)# exit
HP9300C(config)# write memory
11 - 47
