HP DC ProCurve Switches
4000M and 8000M
Installation Guide
Edition 1
Manufacturing Part Number: Z7017-90002
September 2001
© Copyright 2001 Hewlett-Packard Company

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProCurve 4000M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP ProCurve 4000M

Summary of Contents for HP ProCurve 4000M

  • Page 1 HP DC ProCurve Switches 4000M and 8000M Installation Guide Edition 1 Manufacturing Part Number: Z7017-90002 September 2001 © Copyright 2001 Hewlett-Packard Company...
  • Page 3 Notices This document contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard Company. Disclaimer The information contained in this document is subject to change without notice.
  • Page 4 The HP DC ProCurve Switches provide DC power versions of the HP ProCurve 4000M and 8000M Switches for Central Office applications. • Chapter 1 , “Overview,” on page 9 describes the HP DC ProCurve Switch features and ordering information. • Chapter 2 , “Installing the Switch in a Seismic Rack,” on page 15 describes how to install the HP DC ProCurve Switch in a seismic rack.
  • Page 5 Safety Information Documentation reference symbol. If the product is marked with this symbol, refer to the product documentation to get more information about the product. WARNING A WARNING in the manual denotes a hazard that can cause injury or death. CAUTION A CAUTION in the manual denotes a hazard that can damage equipment.

  • Page 7: Table Of Contents

    Contents Contents 1. Overview Introduction ............... . 10 Accessories and Ordering Information .
  • Page 8 Contents Japan ................42 European Community .

  • Page 9: Overview

    Overview This chapter describes the HP DC ProCurve Switches.

  • Page 10: Introduction

    Overview Introduction Introduction The HP DC ProCurve switches 4000M and 8000M are for the Central Office (CO) and other environments requiring DC powered NEBS compliant switches. Some of the switch features are: • Fully NEBS Level-3 compliant, including earthquake Zone-4.

  • Page 11: Accessories And Ordering Information

    • Power Cable Options for 8000M • #opt 001, Redundant DC power supply • #opt 002, Rack-mount kit for an HP Seismic Rack • #opt 011, 10/100 Base-T Module (8-port RJ-45) • #opt 012, Gigabit-SX Module (1-port SC optical) • #opt 013, 100 Base-FX Module (4-port SC optical) •...

  • Page 12: Base Product - Z7017F 4000M

    • Power Cable Options for 4000M • #opt 001, Redundant DC power supply • #opt 002, Rack-mount kit for an HP Seismic Rack • #opt 011, 10/100 Base-T Module (8-port RJ-45) • #opt 012, Gigabit-SX Module (1-port SC optical) • #opt 013, 100 Base-FX Module (4-port SC optical) •...
  • Page 13 Accessories and Ordering Information The field upgrade products listed above are the only add-on modules NOTE supported for the DC ProCurve 4000M and 8000M products. They are functionally equivalent to the modules supported by the AC ProCurve 4000M and 8000M products...
  • Page 14 Overview Accessories and Ordering Information Chapter 1...

  • Page 15: Installing The Switch In A Seismic Rack

    Installing the Switch in a Seismic Rack This chapter describes how to install the HP DC ProCurve Switch in a seismic rack.

  • Page 16: Introduction

    Installing the Switch in a Seismic Rack Introduction Introduction NOTE If t he HP DC ProCurve Switch is already installed in a seismic rack, skip this chapter and go directly to Chapter 3 , “Connecting the DC Power Supply,” on page 21. Chapter 2...
  • Page 17 Installing the Switch in a Seismic Rack Introduction The HP DC ProCurve switch can be fitted with a seismic rack mount kit for installation in the HP Seismic Rack, or equivalent. This solution fulfills NEBS requirements for telecommunication equipment installed in a Central Office.

  • Page 18: Seismic Rack Kit

    Installing the Switch in a Seismic Rack Seismic Rack Kit Seismic Rack Kit The table below shows the parts included for this installation, and identification numbers for each component as it appears in Figure 2-1 on page 19. Table 2-1 Earthquake Rack-Mount Components Description Quantity...

  • Page 19: Installing The Switch In The Rack

    Installing the Switch in a Seismic Rack Installing the Switch in the Rack Installing the Switch in the Rack Step 1. Attach the switch to the seismic tray using eight (8) screws Step 2. Position the eight (8) nut-clips in the appropriate locations on the rack mounting rails.
  • Page 20 Installing the Switch in a Seismic Rack Installing the Switch in the Rack Chapter 2...

  • Page 21: Connecting The Dc Power Supply

    Connecting the DC Power Supply This chapter provides information for connecting DC power to the HP DC ProCurve Switch in a Central Office environment.

  • Page 22: Introduction

    Connecting the DC Power Supply Introduction Introduction The DC power supplies are DC-to-DC converter modules, enabling the switch to be operated from centralized -48 or -60 V DC power sources. Two Power Supplies When two power supplies are installed, the DC power supplies have the following features: •...

  • Page 23: Connecting To The Dc Power Source

    Connecting the DC Power Supply Connecting to the DC Power Source Connecting to the DC Power Source CAUTION Disconnect DC power from the power supply BEFORE installing or removing the supply. Not disconnecting the power first can damage the power supply or switch. Read this manual for proper handling procedures.
  • Page 24 Connecting the DC Power Supply Connecting to the DC Power Source The DC power supply has a rear panel-mounted 4-pin DC power connector. See Figure 3-1. Figure 3-1 DC Power Rear Panel (with optional second power supply shown) Z7017-60001 Z7017-60001 Disconnect DC power from DC power Disconnect DC power from DC power BEFORE removing power supply to...
  • Page 25 Connecting the DC Power Supply Connecting to the DC Power Source The unit has been supplied with a suitable power cable (Z7017-60006). See Table 3-1 and Figure 3-2 for the connector pinout details. The power cable must be connected to the rear panel-mounted 4-pin DC power connector and to the frame’s fuse or circuit-breaker panel.

  • Page 26: Safety Grounding Procedures

    Connecting the DC Power Supply Safety Grounding Procedures Safety Grounding Procedures Each power supply has an M5 stud, starwasher, and nut on the rear panel for connecting to earth ground. Both power supplies should be connected to earth ground using a minimum 1.3 mm (16 AWG) cable with a suitable Listed/Certified M5, or equivalent crimp-on ring terminal.
  • Page 27 Connecting the DC Power Supply Connecting the Power Supply For complete power redundancy, connect each power supply to a separate NOTE power source. This protects the system from power failure if one power source fails. Connecting both power supplies to the same power source protects the system if one power supply fails, but not from a failure in the power source.
  • Page 28 Connecting the DC Power Supply Connecting the Power Supply Step 3. Attach a plastic tie wrap around the power cable and through the hole on the back of the rack mount tray to provide cable strain relief. Pull the tie snug until the cable is securely attached and cut off the excess tie.
  • Page 29 Connecting the DC Power Supply Connecting the Power Supply Step 4. Verify that the power supply is installed correctly by checking the LEDs on the Switch and the Switch Engine Module. The Power Status LED should be on continuously and not flashing. If the Power Status LED and the switch Fault LED are flashing, see the section “Troubleshooting”...

  • Page 30: Troubleshooting

    Connecting the DC Power Supply Troubleshooting Troubleshooting If the Power Status LED and the switch Fault LED are flashing, one of the following is probably occurring: • The power supply is not connected to an active DC power supply • The power supply is not properly installed •...

  • Page 31: Replacing The Dc Power Supply

    Replacing the DC Power Supply This chapter provides information for replacing the HP DC ProCurve Switch DC power supply.

  • Page 32: Replacing The Dc Power Supply

    Replacing the DC Power Supply Replacing the DC Power Supply Replacing the DC Power Supply The DC power supply replacement steps are: 1. Disconnect the DC power. 2. Disconnect the earth ground. 3. Remove the installed power supply from the power supply slot. 4.

  • Page 33: Removing The Power Supply

    Replacing the DC Power Supply Replacing the DC Power Supply Removing the Power Supply Step 1. Unplug the power cable from the power supply. Step 2. Disconnect the ground cable from the grounding lug near the power connector on the face plate of the power supply. Step 3.

  • Page 34: Installing The Power Supply

    Replacing the DC Power Supply Replacing the DC Power Supply Installing the Power Supply Step 1. Insert the power supply into the opening. Lower it until it rests on the bottom of the switch chassis. Slide it in until it connects to the connector at the back of the slot. The power supply face plate should be flush with the back of the switch.

  • Page 35: Specifications

    Specifications This Appendix provides specifications for the HP DC ProCurve Switch.

  • Page 36: Specifications

    Specifications Specifications Specifications IMPORTANT Except as noted below, refer to the specifications provided in the HP ProCurve Switch 4000M and 8000M Installation Guide. NEBS Compliance The HP DC ProCurve Switch has been tested by an independent laboratory and found compliant with Telcordia (formerly Bellcore) NEBS GR-63-CORE, Network Equipment-Building System (NEBS) Requirements: Physical Protection;...

  • Page 37: Environmental

    Specifications Specifications Environmental Temperature, From -60 to +4000 m (-197 to +13,123 ft.): +5 to +40 °C continuous operation -5 to +55 °C NEBS short-term operation -40 to +70 °C storage and transportation Relative Humidity, non-condensing: 5 to 85% R.H. at 40 °C continuous operation 90% R.H.

  • Page 38: Emc

    Specifications Specifications NEBS GR-1089-CORE FCC Part 15 Class A ICES-003 Class A EN 55022 / CISPR 22 Class A EN 55024 VCCI Class A AS/NZS 3548 Class A Appendix A...

  • Page 39: Regulatory Information

    Regulatory Information This appendix provides regulatory information for the HP DC ProCurve Switch.

  • Page 40: Safety Information

    Regulatory Information Safety Information Safety Information See Section C, Safety and EMC Regulatory Statements, in the HP ProCurve Switch 4000M and 8000M Installation Guide for multilingual safety information. Appendix B...

  • Page 41: Emc Regulatory Statements

    Regulatory Information EMC Regulatory Statements EMC Regulatory Statements The following EMC regulatory statements apply to the HP DC ProCurve Switch. U.S.A. FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment.
  • Page 42 Regulatory Information EMC Regulatory Statements Japan VCCI Class A Appendix B...
  • Page 43 19420 Homestead Road Cupertino, California 95014 declares that the product: Product name: HP DC ProCurve Switch 4000M, 8000M, and 8000M/RDC Model number: Z7017Y, where Y can be any letter A through Z. Product Options: conforms to the following Product Specifications:...
  • Page 44 Regulatory Information EMC Regulatory Statements Appendix B...
  • Page 46 Printed in USA Order Part Number Z7017-90002 E0100 Z7017-90002 Manufacturing Part Number...
