Installation and Basic Configuration Guide
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-write access. The System configuration
dialog is displayed.
2. Click on the plus sign next to Configure in the tree view to expand the list of configuration options.
3. Click on the plus sign next to System.
4. Select the Boot Sequence link to display the Boot Sequence List panel.
5. Select the primary boot source by clicking on the radio button next to the name.
NOTE: You cannot select the interactive option using the Web management interface. To select this option,
use the CLI.
6. To specify a secondary boot source, go to step 5. The device tries the boot sources in the order you specify
them.
7. Select Add to add the change to the device's running-config.
8. If you want the change to remain in effect following the next system reload, select the Save link to save the
configuration change to the startup-config file.

Using SNMP to Upgrade Software

You can use a third-party SNMP management application such as HP OpenView to upgrade software on an HP
device.
NOTE: In software releases earlier than 07.5.0.xx, the SNMP agent does not check for type validity with the
SNMP version. In software release 07.5.xx and above, the SNMP agent does not send a reply for a varbind, if the
type of the varbind is not a known type for that version of SNMP. For example, MIB objects of type Counter64
cannot be retrieved using a v1 packet, as Counter64 is a v2c and v3 type.
NOTE: Make sure you use the correct procedure for your device and processor type. For example, do not use
the Management Processor procedure to upgrade the Switching Processors on a module.
NOTE: The syntax shown in this section assumes that you have installed HP OpenView in the "/usr" directory.
NOTE: HP recommends that you make a backup copy of the startup-config file before you upgrade the software.
If you need to run an older release, you will need to use the backup copy of the startup-config file.
Management Processorredundant Management ProcessorManagement Processornhphp
the flash code into the device's secondary flash area.
Upgrading Switching Processors on a Chassis Device
Use this procedure to upgrade flash code on the Switching Processors on the T-Flow Redundant Management
Module.
1. Configure a read-write community string on the HP device, if one is not already configured. To configure a
read-write community string, enter the following command from the global CONFIG level of the CLI:
snmp-server community <string> ro | rw
where <string> is the community string and can be up to 32 characters long.
2. On the HP device, enter the following command from the global CONFIG level of the CLI:
no snmp-server pw-check
