Installation and Basic Configuration Guide
USING THE CLI
Enter the following command at any CLI level. This example shows the display for the IP sub-net and IPX network
VLANs configured in the examples in "Configuring an IP Sub-Net VLAN with Dynamic Ports" on page 11-32 and
"Configuring an IPX Network VLAN with Dynamic Ports" on page 11-32.
HP9300(config)# show vlans
Total PORT-VLAN entries: 2
Maximum PORT-VLAN entries: 8
legend: [S=Slot]
PORT-VLAN 1, Name DEFAULT-VLAN, Priority level0, Spanning tree Off
Untagged Ports: (S2)
Untagged Ports: (S2) 17 18 19 20 21 22 23 24
Untagged Ports: (S4)
Untagged Ports: (S4) 17 18 19 20 21 22 23 24
Tagged Ports: None
PORT-VLAN 10, Name IP_VLAN, Priority level0, Spanning tree Off
Untagged Ports: (S1)
Tagged Ports: None
IP-subnet VLAN 1.1.1.0 255.255.255.0, Dynamic port enabled
Name: Mktg-LAN
Static ports: None
Exclude ports: None
Dynamic ports: (S1)
PORT-VLAN 20, Name IPX_VLAN, Priority level0, Spanning tree Off
Untagged Ports: (S2)
Tagged Ports: None
IPX-network VLAN 0000ABCD, frame type ethernet_ii, Dynamic port enabled
Name: Eng-LAN
Static ports: None
Exclude ports: None
Dynamic ports: (S2)
Syntax: show vlans [<vlan-id> | ethernet <portnum>]
The <vlan-id> parameter specifies a VLAN for which you want to display the configuration information.
The ethernet <portnum> parameter specifies a port. If you use this parameter, the command lists all the VLAN
memberships for the port.
USING THE WEB MANAGEMENT INTERFACE
To display VLAN configuration information:
1. Log on to the device using a valid user name and password for read-only or read-write access. The System
configuration dialog is displayed.
2. Click on the plus sign next to Configure in the tree view to expand the list of configuration options.
3. Click on the plus sign next to VLAN in the tree view to expand the list of VLAN option links.
4. Click on the Port link to display the Port-based VLAN table or the Protocol link to display the Protocol-based
VLAN table.

Displaying VLAN Information for Specific Ports

Use one of the following methods to display VLAN information for specific ports.
11 - 64
