2 Hardware Installation
Finalize and Test the Hardware
2. Connect the printer to the terminal.
3. Set the options on the printer.
4. Proceed to
Task 2-5: Finalize and Test the
Hardware
1. Verify that the DEFINITY AUDIX system is in the AUDIX state.
To do so, check the faceplate of the DEFINITY AUDIX system. If the
system is in the AUDIX state, the LEDs will look as follows: red - any state,
green - off, yellow - on.
2. Log in to the DEFINITY AUDIX system at the terminal (both terminals if you
have installed more than one) to verify that the terminals and modems (if
applicable) are connected and set up correctly.
d. Be sure that the printer has paper, the ribbon is properly installed,
and the cover is closed.
a. Connect one end of the printer cable to either the serial or parallel
port on the terminal depending on which type of terminal and
printer you are installing. Secure the connector with the captive
screws.
NOTE:
If you are connecting a serial printer to the DTE connector on
a 715 terminal, you must connect a null modem between the
printer and the terminal.
b. Connect the other end to the matching port (serial or parallel) on
the printer.
Task 2-5.
NOTE:
If the login prompt is not displayed, press
a. At the login prompt, type craft and press
NOTE:
To send the information to the DEFINITY AUDIX system, the
key (part of the numeric keypad) must be pressed
RETURN
after you type a command or a response to a prompt. Note
that on some keyboards, this key is labeled
.
RETURN
The system displays the Password prompt.
b. Enter crftpw
The system displays the Enter terminal type prompt.
Issue 1
May 1999
once or twice.
RETURN
.
RETURN
instead of
ENTER
2-25
