B Switch Administration Worksheets
Administer the Voice Ports as Stations (Digital Port Emulation)
AUDIX system is running in control link (CL) integration in a DCS environment,
additional copies of the relevant worksheets are needed for each remote switch
in the DCS network.
In this appendix, the following conventions apply for values listed in the
right-hand column of the worksheets:
[values in plain type and brackets] are the defaults
[values in bold type with brackets] are recommended
values in bold type with no brackets are required

Worksheet B-1: Administer the Voice

Ports as Stations (Digital Port Emulation)

Date
Prepared by
Contact telephone number
The information in the following tables is required for administering the DEFINITY
AUDIX voice ports on the switch. For more information on these fields, see
Chapter 4.
For digital port emulation, DEFINITY AUDIX can emulate either the TN754 circuit
pack (8 port board) or the TN2181 circuit pack (12 port board). In either case, all
digital ports must be administered on the switch (either 8 or 12) and on the
DEFINITY AUDIX system regardless of how many ports the customer purchased.
However, only the number of ports actually purchased are administered in the
hunt group.
Extension
Complete next table.
Set type options (TN754 and TN2181)
Port
Complete next table.
Name
Complete next table.
Lock Messages
_________________________
_________________________
_________________________
See next table
7405D (S75, G1,
G3V1-V4, R5, R6,
ProLogix R6)
ADX16D (G3R7 and
higher; ProLogix R7
and greater)
See next table
See next table
n
