2 Hardware Installation
Install the DEFINITY AUDIX System Assembly
The combined states of the LEDs listed in
status of the system, including minor and major alarms. When the
DEFINITY AUDIX SYSTEM boots up, the LED states should match the boot
up sequence shown in the following table:
Table 2-1. LED States During Normal Boot Up Sequence
Red
(failure)
On
On
Any value
Any value
Any value
1. The time is the period that the LED lights are displayed.
See DEFINITY AUDIX System — Maintenance, 585-300-121 for a
complete list of the status and alarm states.
If the DEFINITY AUDIX system does not come up to the AUDIX state within
10 minutes, write down the states displayed on the LEDs, and refer to the
associated troubleshooting procedures in DEFINITY AUDIX System —
Maintenance , 585-300-121.
8. Continue with
Green
(maintenance)
On
On
On
Off
Off
NOTE:
If the system passes through the normal AUDIX state (Red - off,
Green - off, Yellow - on) but ends with the following state:
Red - on, Green - off, Yellow - on
you can ignore it at this time. This is an alarm state indicating a
software error that probably resulted from a port board alarm. The
alarm should turn off when you administer the ports.
Task 2-2.
Table 2-1
Yellow System Status
(system)
On Board inserted, main CPU is not
running (for a very short time
Flashing Firmware running diagnostic
re-boot
Off Booting software (for a short
1
time )
Flashing UNIX is running (for a short
1
time )
On AUDIX state
Issue 1
May 1999
2-8
indicate the current
1
)
