A Switch Carrier Configuration Worksheets
Port Slot Assignments (Before Carrier Rearrangement)
3. Complete
DEFINITY AUDIX system will use and where the other circuit packs should
be placed. Give the completed
rearrange the carrier circuit packs.

Worksheet A-1: Port Slot Assignments

(Before Carrier Rearrangement)

Date
Prepared by
Contact telephone number
2. The DEFINTY AUDIX system only needs one port slot in a ProLogix if it is installed in slot 6.
Keep in mind the ease with which circuit packs can be moved.
Circuit packs are listed below in order of easiest to most difficult to
move:
— Analog line packs: stations, CO, WATS, DID, and AUX
— Hybrid line packs
— Digital line packs
NOTE:
(Try to avoid packs associated with any of the
following: data sets with many feature buttons,
console, data lines, CEO's line, speech synthesizers,
announcements.)
— BRI line packs
— Tone detector packs
— Tie Trunk packs
— ISDN packs/DS1 packs
— Pooled modem packs
— Tone Clock Board (not movable)
— ASAI-related packs: BRI/LAN Gateway
The above list is not complete. The switch may include other packs
that are difficult to move.
Worksheet A-2 to show which two
2
contiguous slots the
Worksheet A-2 to the technician who will
_________________________
_________________________
_________________________
