Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
I Changing Switch Integrations, Port Emulations, and Number of Voice Ports
Changing from CL Integration — Analog to DS Integration — Digital
Changing from CL Integration —
Analog to DS Integration — Digital
This section describes the tasks needed to change the switch administration of
the DEFINITY AUDIX system to DS integration from CL integration.

Verifying the Emulation and Integration Types

Before changing the switch from supporting CL integration to supporting DS
integration begins, the remote service center must change the integration
defined within the DEFINITY AUDIX system. Do the following to be sure the
integration has been changed.
1. At the DEFINITY AUDIX administration terminal, log into the DEFINITY
AUDIX system.
2. On the DEFINITY AUDIX command line, enter display
system-parameters customer-options
The system displays the System Parameters Customer Options screen.
3. Check the Port Emulation Type field for one of the following values:
4. Check the Switch Integration Type field for display-set
5. If these values are not present in one or both of the fields, call the remote
service center immediately to arrange to change the values.
tn2181 (12-port system)
tn754 (8-port system)
NOTE:
Reboot the DEFINITY AUDIX system after the integration (and
emulation) designations have been changed and before you do
Removing Voice Ports.
Issue 1
May 1999
I-3
