Hardware Installation

Worksheets Needed
Hardware Installation
This chapter describes the tasks required to install the DEFINITY AUDIX system
and peripheral hardware.
You can install the DEFINITY AUDIX system in any of the following switches.
DEFINITY Communications System Generic 3 (G3i [V1-V4, R5 or greater],
G3s [V1-V3], G3vs [V1-V4,R5 or greater] , G3si [V4, R5 or greater])
ProLogix (R6 or greater)
The DEFINITY AUDIX system installation tasks are virtually the same for all switch
types. Therefore only one set of tasks is provided. These installation tasks
include:
Task 2-1 - "Install the DEFINITY AUDIX System Assembly"
Task 2-2 - "Connect to the System Adaptor Cable"
Task 2-3 - "Install the Terminals"
Task 2-4 - "Install the Printer (Optional)"
Task 2-5 - "Finalize and Test the Hardware"
Worksheets Needed
Before beginning these tasks, make sure you have the completed the following
worksheets.
Worksheet A-1: Port Slot Assignments (Before Carrier Rearrangement)
Worksheet A-2: Port Slot Assignments (For Carrier Rearrangement)
Worksheet A-3: Slot Locations for the DEFINITY AUDIX System Assembly
Worksheet C-2: Activate IMAPI for the AUDIX Server Hardware (LAN)
Options
Worksheet C-9: Set Up Alarm Origination
