This appendix contains a list of option settings for supported terminals and
modems, although in most cases you must refer to the appropriate manual
supplied with the terminal and modem for procedures to set these options.
Terminal Option Settings
This section lists the option settings required for a terminal or PC to work
effectively with the DEFINIITY AUDIX system. If the terminal is connected to both
the switch and the DEFINITY AUDIX, it must be administered in the dual port
mode so that users can toggle between the two systems.
!
CAUTION:
If you connect a terminal or PC to a DEFINITY AUDIX system installed in a
DC-powered switch, you must install an opto-isolator in the circuit. Refer to
Task 2-3A
Following are a list of important terminal settings. Refer to the appropriate manual
supplied with the terminal for specific instructions on setting these options.
in
Chapter 2
for installation instructions.
