Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
2 Hardware Installation
Install the Terminals
If you can't log in successfully, contact the remote service center.
7. Continue with
Task 2-3C: Installing an Additional
Administration

Terminal via Asynchronous Data Units (ADUs)

This task describes how to connect a terminal via ADUs to Port B, although the
same procedure can be used to connect the terminal to Port A.
Refer to Figure 2-9
DEFINITY
system
TN568
circuit
pack
Z3A
Asynchronous
Data Unit
RS-232
cable
Figure 2-9. Installing an Additional Administration Terminal to DEFINITY AUDIX via
ADUs
Task 2-4.
when performing this task.
adapter cable
Port C
RS-232
Port B
cable
Port A
2012D
power
supply
103A
Modular
cord
D8AM-87
crossover
Administration
cord
terminal
cydxsl05 AWF 021899
External modem connection
Z3A
Asynchronous
Modular
Data Unit
cord
Main Distribution
Frame
(MDF)
Issue 1
May 1999
Main Distribution
Frame
103A
(MDF)
Local
engineered
wiring
2-19
