I: Reboot The Definity Audix System - Lucent Technologies DEFINITY AUDIX Installation And Administration Manual

Installation and Switch Administration for G3i/G3s/G3vs/R5vs/R5si/ProLogix
Switches, TN2181 Emulation, Display Set Integration 585-300-122
5 Initial Definity AUDIX Administration
Perform Initial DEFINITY AUDIX Administration
7. Move the cursor to the IMAPI Session Timeout field. This is the
amount of time that a session can be inactive before the user is logged out
of the mailbox. Intervals can be set in five-minute increments from 5 to 60
minutes. Leave it at 5. After logging out, the user will have an active
TCP/IP connection to the AUDIX server for 5 minutes.
8. Do not change the value in the LAN IP Address field. This is the IP
address assigned to the AUDIX server by the LAN administrator.
9. Obtain the subnet mask number from the LAN administrator. Move the
cursor to the LAN Subnet Mask field and type in a subnet mask number.
Part of this number matches the network IP address, while the remaining
part contains the host interface address. (Usually, 255.255.255.0 will
work.)
10. Move the cursor to the Default LAN Gateway IP Address field and
type in the default LAN gateway IP address. This is the LAN server
address to which all unknown addresses will be sent for resolution. It is
also supplied by the LAN administrator and has the same form as the LAN
IP Address and subnet mask number.
11. Press
12. When the IP, Subnet mask, and Gateway IP address fields are set, a call
must be made to the underlying TCP/IP software to assign these numbers
to the interface.
13. If you changed either the customer or IMAPI option settings, reboot the
DEFINITY AUDIX system.
14. Continue with
Task 5-1I: Reboot the DEFINITY AUDIX System
1. With the cursor on the DEFINITY AUDIX command line, type reset system
reboot and press
The system displays the Reset System Reboot screen.
(Enter) to save the changes.
F3
Task 5-1I.
.
RETURN
Issue 1
May 1999
5-14
