1 Prerequisites
Verify the Selected Site
circuit card of the Definity Audix system. DS integration uses a channel internal to
the switch that would otherwise be used to transfer display-set information. You
need to know which integration type - DS or CL - to set up for this installation. If
you do not know the integration, contact the project manager or the remote
support center before proceeding.
Task 1-1: Verify the Selected Site
Defining and ensuring that the site meets the DEFINITY AUDIX system
requirements is the responsibility of the Project Manager and the customer, and
must be completed before you install the DEFINITY AUDIX system. The
guidelines are listed here so that you are aware of these requirements.
Verify that the site selected for the switch and the DEFINITY AUDIX system
provides the following:
For a DEFINITY AUDIX system installed in an existing switch, two
contiguous slots in a switch carrier to house the DEFINITY AUDIX system.
If your switch carrier is a CMC however, the system only requires one slot
if you install it in slot 6. (see
slots on the switch.)
Easy access for cabling
Adequate work space for the system administrator and operators
A temperature range of 65° F to 85° F (18° C to 29° C)
A humidity range of 20 to 60%, non-condensing.
The site must be secure and provide protection from excessive sunlight,
heat, cold, chemicals, static electricity, magnetic fields, vibration, and
particulate matter.
Task 1-2: Gather the Required Tools
To install an DEFINITY AUDIX system, you must have the following tools:
No. 1 or No. 2 Phillips screwdriver
Narrow width, flat blade screwdriver
1/4-inch nut driver (recommended)
Antistatic grounded wrist strap
Appendix A for details on configuring the port
