Hardware Installation

This chapter describes the tasks needed to install the DEFINITY AUDIX system
hardware and peripheral hardware.
You can install the DEFINITY AUDIX system in any of the following switches.
System 75 R1V3
DEFINITY Communications System Generic 1 (G1)
DEFINITY Communications System Generic 3 (G3i, G3s, G3vs,and G3r:
all versions of all switches)

Hardware Installation Tasks

The DEFINITY AUDIX system installation tasks are virtually the same for all switch
types. Therefore only one set of tasks is provided, with any differences for switch
types indicated in the instructions. These installation tasks include:
Task 5: Install the DEFINITY AUDIX system hardware assembly.
Task 6: Connect the alarm board and LAN cables (optional).
Task 7: Install the terminals.
Task 8: Install the Control Link cable — CL mode only (optional).
Task 9: Install the optional printer.
Task 10: Finalize and test the hardware.
