Item Feature
L Hard Drive Status LED
(green/amber)
M System Reset button

Platform Rear

The figure below shows the features found at the rear of the platform.
Item Description
A Video port, standard VGA compatible, 15-pin connector
B Serial port connector. Emergency Management Port access is provided through the serial port.
C PCI Slots
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
On
Blinking
Indicates hard drive activity and fault status.
Green
Green
Amber
Amber
Amber
Resets the system
Figure 5. Intel
A
B
1 2
I
G H J K L
PCI Express* x8 (hot-plug)
PCI-X* 133MHz, 64-bit (hot-plug)
PCI Express* x4 (hot-plug)
PCI Express* x4 (hot-plug)
PCI Express* x4 (hot-plug)
Description
Inactive
Active
On
Blinking
On
Slow Blinking
(~1 Hz)
Fast Blinking
(~2.5 Hz)
®
Local Control Panel
C D
F
E
3 4 5 6 7
N
O
M
No access
Access
A hard drive is being
initialized
A hard drive is active
Hard drive/slot failure
A predictive hard drive/slot
failure or rebuild in process
Hard drive rebuild
interrupted or rebuild on
empty slot
P
TP01507
