13. Remove the center brace. For instructions, see
14. Remove the plastic PCI slot dividers"
Push on the two release latches. See letter "A" in Figure 115.
Lift the dividers from the server. See letter "B" in the figure.
15. Disconnect all cables connected to the main board.
16. If the optional external SCSI connector is installed, press down on the tab and push inward as
shown in Figure 105. Drape the cable over the side of the chassis out of the way.
"Removing the Center
A

Figure 115. Removing the PCI Dividers

Brace", page 176.
B
TP01494
211
