Figure 4. Front Panel Controls And Indicators - Intel SR6850HW4 - Server Platform - 0 MB RAM Product Manual

D System Status/Fault LED
(green/amber)
E System Power LED (green)
F System ID LED (blue)
G System Reset button
H System Power button
I System ID button
K NMI button
Front Panel Connectors
J Video connector
L Three USB connectors
Description
Indicates system status.
Off
Green, On
Green,
Blinking
Amber, On
Amber,
Blinking
Indicates system power status.
Off
On
Off
Blinking
On
Helps identify the system. This is useful to identify a server that is
to be serviced.
Resets the system.
Turns system power on and off.
Turn System ID LED on and off.
Causes a non-maskable interrupt (NMI).
Video port, standard VGA compatible, 15-pin connector.
Three USB 2.0 ports, 4-pin connectors.

Figure 4. Front Panel Controls and Indicators

Not ready AC Power Off, POST error
Ready System booted and ready
Degraded Processor or DIMM disabled
Critical Alarm Critical Power Supply, Blower,
Voltage, or Temperature
failure.
Non-critical Redundant Power Supply or
Alarm Blower failure. Non-Critical
Blower, Voltage, and
Temperature failure.
Power off ACPI: No
Power on ACPI: No
S4 / S5 ACPI: Yes
S1 ACPI: Yes
S0 ACPI: Yes
35
