Part II: Service Guide

Part 2: Service Guide describes procedures that require internal server access.
The Service Guide exists for two audiences, Users and Qualified Service Technicians. The User
Serviceable Platform Components chapter is intended for both Users and Qualified Server
Technicians. One should be a qualified service technician to perform all procedures listed in the
Service Guide.

5 User Serviceable Platform Components

This chapter describes components that the user can install or replace. All other components require
servicing by a qualified service technician.

Tools and Supplies Needed

Phillips* #2 screwdriver
Flat head screwdriver
Antistatic wrist strap (recommended)

Equipment Log

To record the model and serial numbers of the server, all installed options, and any other pertinent
information about the server, see

Removing and Installing the Top Cover

WARNING
Make sure the rack is anchored securely so it will not tilt forward when
the server chassis is extended. A crush hazard exists should the rack tilt
forward. This could cause serious injury.
CAUTIONS
For proper cooling and airflow, do not routinely operate the server with the
cover removed. Do not leave the chassis cover open or a system fan removed
any longer than necessary; system cooling could be reduced.
The server comes with a removable top cover that allows the PCI cards,
memory boards, and the system fans to be hot-swapped, and the system
components to be serviced. With the exception of the components
138
"Equipment Log", page 252.
