Front Panel I/O Board

®
The Intel Server Platform SR6850HW4 Front Panel I/O board provides access to the video and
USB interfaces.
A Front panel board connector
®
The Intel Server Platform SR6850HW4 and SR6850HW4/M Front Panel board provides the
following functions:
USB Port
- External front panel connector for three USB 2.0 ports
-
Filtering for the USB signals
- Bulk Capacitance and fused power for USB ports
Video Output
-
External front panel 15-pin VGA connector
-
Required safety fusing and EMI filtering
Speaker
-
Audible beep-code and alarm speaker

Front Panel Control Board

The front panel control board contains the following front panel buttons and LEDs and connects to
the SCSI-backplane board:
Buttons
-
NMI button
-
System ID button
- System reset button
-
System power button
System status LEDs
- Hard disk drive status

Figure 14. Hot-Plug Memory Board LEDs

A

Figure 15. Front Panel Board Component Location

TP01488
