User Serviceable Platform Components
11. Install the memory board. For instructions, see
Insertion of a Memory
configuration.
12. Re-install the top cover. For instructions, see

Removing DIMMs

CAUTION
Use extreme care when removing DIMMs. Too much pressure can damage
the connector. Apply only enough pressure on the plastic levers to release the
DIMM.
1. Remove the top cover. For instructions, see
2. Remove the memory board. For instructions, see
161 or "Cold Removal of Memory
configuration.
3. Remove the memory board DIMM cover from the memory board:
-
Pull out on the latch labeled "A" in Figure 82.
-
Press on the tab labeled "B" in Figure 82.
-
Press on the tab labeled "C" in Figure 82.
- Lift the memory board DIMM cover from the memory board. See letter "D" in Figure 82.
4. Open the plastic levers on each end of the DIMM socket(s). The DIMM will lift from the
socket.
5. Hold the DIMM only by the edges. Do not touch the DIMM components or the gold edge
connectors. Store it in an antistatic bag.
6. Install replacement DIMMs if necessary. For instructions, see
7. Install the memory board DIMM cover on the memory board:
- Line up the two tabs labeled "A" in Figure 84.
-
Press on the tab labeled "B" in Figure 84.
8. Install the memory board or install a memory board air baffle into the memory board slot. For
instructions, see
Memory Board"on page 165, depending on your server configuration.
9. Re-install the top cover.
170
Board", on pages 164 or 165 respectively, depending on your server
Board" on page 165, depending on your server
"Hot Insertion of a Memory
Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
"Hot Insertion of a Memory
"Installing the Top Cover", page 140.
"Removing the Top Cover", page 139.
"Hot Removal of a Memory
"Installing
Board" on page 164, or
Board" or "Cold
Board" on page
DIMMs", page 167.
"Cold Insertion of a
