Configure Users Screen
The Configure Users Screen provides a mechanism for configuring user access to LAN and
Serial/Modem channels. The maximum number of users that can be configured for a system
depends on that system. The screens allow configuration of user settings like username, password,
and the per-channel configuration for each user.
Enable User: The Enable User checkbox allows you to enable or disable this user. When the
checkbox is enabled, all other configuration items for this user become enabled.
Username: The Username edit box is used to allow a custom name to be assigned to a user
configuration. For User 1, the name must be set to Anonymous. Therefore, this option is
disabled for User1.
Set Password for this User: The Set Password button displays a dialog box that allows a
password to be set for the selected user.
LAN Channel 1 Privilege Level Limit: The LAN Channel 1 Privilege Level Limit list allows
you to select the privilege level for the user being configured. The global privilege level set for
LAN channel access takes precedence over the user privilege level. For example, if the LAN
channel is configured for user access only, then users are limited to user operations regardless
of the user privilege level.
LAN Channel 2 Privilege Level Limit: The LAN Channel 2 Privilege Level Limit dropdown
list allows you to select the privilege level the user being configured.
Figure 37. User Configuration Screen
99
