Intel SR6850HW4 - Server Platform - 0 MB RAM Product Manual page 241

Password
Clear
3
J4A1
Breaker Type
3
Name
Password Disable or Clear
BIOS WP
BIOS Recovery
BIOS Clear CMOS
CB_TYPE (circuit breaker
type)
PHPDIS
FRB3 Disable
BIOS Write
Protect
Default Default
Enabled Enabled
3
J4A2
Circuit
B
Default
100 V
15 A
J4G3
CPU 3 CPU 4
Location Default
J4A1 Stuff
Empty
J4A2 Stuff
Empty
J4A3 Stuff
Empty
J4A4 Stuff
Empty
J4G3 Stuff
Empty
J4G5 Stuff
Empty
J8C1 Stuff
Empty
BIOS NVRAM
Recovery Clear
Default Default
Enabled Enabled
3 3
J4A3 J4A4
CPU 2 CPU 1
Stuffed Jumper State
(Default in Bold)
1-2 = Password Enabled
2-3 = Password Disabled / Cleared
1 – 2 = BIOS Unprotected
2 – 3 = BIOS write protected
1-2 = Normal Boot
2-3 = BIOS Recovery
1 – 2 = BIOS_CLR_CMOS
2 – 3 = Forced CMOS clear
1 – 2 = Circuit Breaker – Other
2 – 3 = Circuit Breaker – 100V 15Amp
1-2 = PHP Enabled
2-3 = PHP Disabled
1 – 2 = FRB3 timer enabled
2 – 3 = FRB3 timer disabled
A
TP01446
241
