Platform Description

Platform Features

The platform features are outlined in the following table.
Table 1. Chassis Feature Summary
Feature
Dimensions (6U rack-mount
platform)
Clearance requirements
Configuration
flexibility/scalability
Serviceability
Availability
32
Description
Height: 10.3 inches (262 mm)
Width: 17.6 inches (447 mm)
Depth: 27.8 inches (706 mm)
Weight of fully configured system: 105 lbs (48 kg)
Front clearance: 3 inches (76 mm)
Side clearance: 1 inch (25 mm)
Rear clearance: 6 inches (152 mm)
Support for one to four processors
Support for at least two generations of processors
Support for up to ten Ultra320* SCSI hard drives
Support for up to seven PCI adapters
Support for up to 64GB Double Data Rate-II (DDR2) 400 MHz
Synchronous Dynamic Random Access Memory (SDRAM)
memory DIMMs
Option for Front Panel Control Module with or without LCD
Option for 2Gb Fiber Channel Module
®
Option for Intel Management Module (Professional or Advanced)
Front access to hot-swap hard disk drives
Top access to hot-swap fans
Rear access to hot-swap power supplies
System power and system status LEDs
System ID buttons and LEDs on front panel and rear of system
Memory configuration and status LEDs
Processor failure LEDs
Color-coded parts to identify hot-swap and non-hot-swap
serviceable components
Four hot-plug PCI Express* slots
Three PCI-X* slots
Two 1570W power supplies in a redundant (1+1) configuration
Dual power cords (1+1) when two power supplies are installed
Six hot-swap system fans in a redundant (5+1) configuration
Ten hot-swap 1-inch Ultra320* SCSI hard disk drives
Four hot-plug memory boards (OS support required)
RAID on MotherBoard (ROMB) with a battery-backed DDR2
400MHz DIMM for disk cache
Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
