Figure 17. Jumper Locations - Intel SR6850HW4 - Server Platform - 0 MB RAM Product Manual

Password
Clear
Default
Enabled
3
J4A1
Circuit
Breaker Type
3
J4J3
1. Observe the safety precautions, warnings, and cautions described in
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see
5. Move the NVRAM Clear jumper at location J4A4 on the main board to cover pins 2 and 3.
6. Install the top cover. For instructions, see
7. Plug in the power cords.
8. Power on the system.
9. Wait for the system to boot into the Error Manager and report the NVRAM has been
cleared.
10. Power down the system and unplug both AC power cords.
11. Remove the top cover. For instructions, see
12. Move the NVRAM Clear jumper at location JAA4 on the main board to cover pins 1 and 2.
13. Install the top cover. For instructions, see
BIOS Write BIOS
Protect Recovery
Default
Enabled
3 3
J4A2 J4A3
B
Default
100 V
15 A
CPU 3 CPU 4 CPU 2

Figure 17. Jumper Locations

"Removing the Top
"Installing the Top
"Removing the Top
"Installing the Top
NVRAM
A
Clear
Default Default
Enabled Enabled
3
J4A4
CPU 1
TP01446
"Information", page
Cover", page 139.
Cover", page 140.
Cover".
Cover".
