CAUTION
Do not attempt to remove any memory board while any of the LEDs are
either on or blinking. If the LEDs do not turn off, your configuration may not
support hot-plug memory board activity. For instructions on non-hot-plug
memory board maintenance, see
"Cold Insertion of a Memory
4. Once all the board LEDs are off, press the latch on the handle (letter "A" in Figure 79) and lift
the memory board handle (letter "B" in the figure.
5. Pull up on the memory board handle to lift the memory board from the server. See letter "C" in
the figure.
6. Install DIMMs, then reinstall the memory board, or install a memory board air baffle:
- For instructions to install DIMMs, see
-
For instructions to install the memory board air baffle, see
Board", page 164.
"Cold Removal of Memory
Board", both on page 165.
"Removing and Installing
B
A

Figure 79. Memory Board Removal

Board" and
DIMMs", page 166.
"Hot Insertion of a Memory
C
TP01417
163
