Server Platform Utilities
A third method to generate a request to reset the system configuration request is by using front
control panel buttons. Use the following steps:
1. Power off the server, but leave it plugged in to the AC power source.
2. Make sure the NVRAM clear jumper at location J4A4 is in the 'not clear' position. See
letter "A" in Figure 17 to locate the jumper block.
3. Hold down the reset button for at least 4 seconds. Continue to hold the reset button down
while completing the next step.
4. While still holding down the reset button, press the power button.
5. Release the On/Off button and the reset button simultaneously.
Upon completion of these steps, the BMC asserts the clear configuration signal to emulate the
movement of the NVRAM Clear jumper. The BIOS clears the system configuration as if the
clear configuration jumper had been moved. The system configuration is cleared only once per
front panel button sequence.
The option to return the system to the defaults using the front panel configuration reset function
can be disabled by removing the clear configuration jumper from the main board. If the jumper
is removed, to prevent this reset, it should be retained.

BIOS Upgrades and Recovery

The BIOS is implemented as firmware that resides in the flash ROMs. Use the DOS based utility
iflash32.exe to upgrade the BIOS.
NOTE
See http://support.intel.com/support/motherboards/server/SR6850HW4/
the latest BIOS release.

BIOS Upgrades iflash32

NOTE
A BIOS upgrade procedure can also be done with the latest available System
Update Package (SUP) for the Intel® Server Platform SR6850HW4 and
SR6850HW4/M. This package is available at:
http://support.intel.com/support/motherboards/server/s/
68 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
for
