9 Servicing the Peripheral Area Components

Installing the External SCSI Cable Assembly

The optional external SCSI cable assembly allows external SCSI components to be connected to the
chassis.
To install the external SCSI cable assembly:
1. Observe the safety precautions, warnings, and cautions described in
5.
2. Turn off all peripheral devices connected to the system.
3. Power down the system and unplug both AC power cords.
4. Remove the top cover. For instructions, see "Removing the Top Cover", page 144.
5. Remove any memory boards or memory board air baffles from Slots C and D. For instructions,
see "Cold Removal of Memory
6. If installed, remove the Fibre Channel Module. For instructions, see
Channel Module", page 156.
7. Connect the end of the SCSI cable labeled either "main Board" or "Baseboard" into the
Channel B SCSI connector.
8. Route the remaining length of cable along the chassis wall and through the air dam to the rear
of the chassis.
9. Bend and route the end of the cable beneath the two memory board and Fibre Channel Module
locations.
10. If installed, remove the filler bracket by pushing down on the latch at the top of it and pulling
the panel from the server. See letter "A" in Figure 105.
