5.2.4.12.3.3.1 Per-Sector Spare Mappings
In these schemes
the spare area. The spare area of each sector is composed of:
• ECC, which must be located after the data it protects
• other data, which may or may not be protected by the sectors ECC
Figure 5-38. NAND Page Mapping and ECC: Per-Sector Schemes
M1
Per-sector spares
Spares covered by sector ECC
per sector ECC mapping.
Mode Size0
Write 1 P
Read 1 P+E
M2
Per-sector spares
Spares covered by sector ECC
per sector, left-padded ECC.
Mode Size0
Write 1 P
Read 10 P
M3
Per-sector spares
Spares covered by sector ECC,
ECC not right-aligned.
Mode Size0
Write 1 P
Read 1 P+E
M4
Per-sector spares
Spares not covered by ECC,
ECC right-aligned per sector.
Mode Size0
Write 2 U+E
Read 2 U
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
Preliminary
(Figure 5-38), each 512-byte sector of the main area has its own dedicated section of
