Registers

3.3.2.14 Receive Interrupt Status (Masked) Register (RXINTSTATMASKED)

The receive interrupt status (masked) register (RXINTSTATMASKED) is shown in
described in Table
Figure 3-39. Receive Interrupt Status (Masked) Register (RXINTSTATMASKED)
31
15
7 6
RX7PEND RX6PEND
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 3-39. Receive Interrupt Status (Masked) Register (RXINTSTATMASKED) Field Descriptions
Bit Field Value
31-8 Reserved 0
7 RX7PEND 0-1
6 RX6PEND 0-1
5 RX5PEND 0-1
4 RX4PEND 0-1
3 RX3PEND 0-1
2 RX2PEND 0-1
1 RX1PEND 0-1
0 RX0PEND 0-1
478
EMAC/MDIO Module
Preliminary
3-39.
5 4
RX5PEND RX4PEND
R-0 R-0
Description
Reserved
RX7PEND masked interrupt read
RX6PEND masked interrupt read
RX5PEND masked interrupt read
RX4PEND masked interrupt read
RX3PEND masked interrupt read
RX2PEND masked interrupt read
RX1PEND masked interrupt read
RX0PEND masked interrupt read
© 2011, Texas Instruments Incorporated
Reserved
R-0
Reserved
R-0
3 2
RX3PEND RX2PEND
R-0 R-0
www.ti.com
Figure 3-39 and
16
8
1 0
RX1PEND RX0PEND
R-0 R-0
SPRUGX9 – 15 April 2011
