USB on-the-go full-speed (OTG_FS)
FIFO_number = 5: 0x0200 0200 + (5
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:16 INEPTXFD: IN endpoint Tx FIFO depth
Bits 15:0 INEPTXSA: IN endpoint FIFOx transmit RAM start address
47.15.19 Host-mode registers
Bit values in the register descriptions are expressed in binary unless otherwise specified.
Host-mode registers affect the operation of the core in the host mode. Host mode registers
must not be accessed in device mode, as the results are undefined. Host mode registers
can be categorized as follows:
47.15.20 OTG Host configuration register (OTG_HCFG)
Address offset: 0x400
Reset value: 0x0000 0000
This register configures the core after power-on. Do not make changes to this register after
initializing the host.
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
1680/1830
