Figure 15 "Backplane to I/O panel connections on the IPE module" (page
94) shows the system monitor cable connections for a Carrier Remote
IPE column. To connect the slave system monitor in the pedestal, follow
the steps in Procedure 16 "Connecting the slave system monitor in the
pedestal" (page
Procedure 16
Connecting the slave system monitor in the pedestal
Step Action
1 Plug the 6-pin modular plug at one end of the NT8D46AL cable
into the J6 6-pin modular jack on the IPE module NT7R61AA
Remote Maintenance Panel assembly.
This cable provides an RS-422 interface to the system monitor.
2 Plug the other end of the NT8D46AL cable 6-pin modular plug
into the J5 modular jack on the system monitor in the pedestal.
3 Check the NT8D22 System Monitor factory switch settings for
the slave system monitor.
Refer to "Option settings" in Circuit Card Reference
(NN43001-311) ().
4 For multiple Carrier Remote IPE modules on a single pedestal,
connect only one Remote Carrier Interface card to the system
monitor in the pedestal.
However, set the system monitor address on all Remote Carrier
Interface cards to be the same as the system monitor address in
the pedestal. This allows any Remote Carrier Interface card to
be connected to the system monitor in the pedestal.
Installing remote MMI terminal cables
The cable that has to be installed at the site is the terminal cable
connecting the terminal or TTY to the DB-9 female connector on the
NT7R61AA Remote Maintenance Panel assembly.
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
95).
Note: Set the system monitor address on the system monitor
card in the pedestal to be identical to the system monitor
address set on the Remote Carrier Interface card using SW11
switch positions 1 through 5. Set the slave system monitor
to the same address that corresponds to the master system
monitor at the local site.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Carrier Remote IPE column installation 95
--End--
