72 Equipment installation and configuration
Installing the NT7R67CA Local daisy-chain cable
This cable is installed only when multiple NT7R51 Local Carrier Interface
cards are equipped and are connected in a daisy-chain.The daisy-chain
configuration provides an easy access to each Local Carrier Interface card
from the local MMI terminal and allows the remote MMI terminal access to
the local SDI port as host.
To install the cable between the Local Carrier Interface card and the
NT7R58AA Maintenance Panel, refer to
connection diagram (local site daisy-chain connection)" (page 199)
follow the steps in
daisy-chain cable" (page
Procedure 5
Installing the NT7R67CA Local daisy-chain cable
Step
1
2
3
Installing SDI and local MMI terminal cables
The NT7R67DA External Maintenance Cable Assembly connects the
SDI card and the TTY terminal to the DB-9 connector on the NT7R58AA
Maintenance Panel assembly located at the rear of the module that houses
the NT7R51 Local Carrier Interface card.
For a single Local Carrier Interface card equipped in the local system, the
P3 DB-9 male DCE connector on the NT7R67DA cable assembly is used
to connect to the local MMI terminal. The P2 DB-9 female DTE connector
is used to connect to an SDI port on an SDI card, which allows the MMI
terminal to access the local system as a host. Refer to
monitor, local MMI terminal, and carrier links cable connections" (page
73) and
(page
Procedure 5 "Installing the NT7R67CA Local
72).
Action
Pull the NT7R67CA Daisy-chain Cable assembly P1 connector
through the cable channel to the front of the module.
Plug the DB-9 male P1 connector of the NT7R67CA cable
assembly into the DB-9 female connector located on the
faceplate of the Local Carrier Interface card.
Plug the DB-9 male P2 connector at the other end of the
NT7R67CA cable assembly into the DB-9 female connector on
the NT7R58AA Maintenance Panel.
Figure 26 "Single LCI connection diagram (local site connections)"
198).
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Figure 27 "Multiple LCIs
--End--
Figure 11 "System
and
