CAUTION
Check if the module is equipped with BTUs that protrude
between card slot connectors in the network shelf. Do not
attempt to install the Local Carrier Interface card in the card
slot immediately to the left of a BTU. If Network Hybrid Kit
NT5D40AA is used instead of BTUs, the Local Carrier Interface
card can be installed into any superloop network card slot with
the network hybrid
Table 9 "Modules supporting Local Carrier Interface cards" (page 59)
modules that provide network card slots, the system options where these
modules are used, and card slots where network cards can be installed.
Card slots that might be physically restricted by BTUs are identified by a
Note in Table 9 "Modules supporting Local Carrier Interface cards" (page
59). The right-hand superloop card slots can be used if the slot does not
have a BTU.
Table 9
Modules supporting Local Carrier Interface cards
Modules System
NT4N41 Core/Net CS 1000M MG, Meridian 1 PBX 81C,
work module CS 1000M SG, Meridian 1 PBX 61C,
NT5D21 Core/Net CS 1000M SG, Meridian 1 Option
work Module 61C, Meridian 1 Option 51C
NT8D35 Network CS 1000M MG, Meridian 1 PBX 81C,
Module Meridian 1 Option 81C, Meridian 1
Option 81
NT9D11 Core/Net CS 1000M SG, Meridian 1 Option 61C
work Module
NT6D39 CPU/Net Meridian 1 Option 61C
work Module
Note: Card slot 11 and 12 can be used with NT8D35BA and NT8D35EA vintage
Network Modules or Network Modules with NT8D3507 backplane, which are
equipped with network Hybrid Kit NT5D40AA instead of BTUs. In older vintage
NT8D35 Network Modules, NT9D11 Core/Network Modules, and NT6D39
CPU/Network Modules, a BTU upgrade kit can be used to replace the BTUs to
be able to use the card slots identified with the Note for the installation of the
Local Carrier Interface card.
The NT5D40AA Hybrids Kit includes four network hybrids required
to replace two BTUs in a single network shelf or module. The kit also
includes the extraction tool that must be used if a network hybrid has to
be removed.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Pre-installation preparation 59
Network card
slot
Card slots 0–7
0-7
5-10, 11&12 (See
Note)
0&1 (See Note),
2-7
1&2 (See Note),
3-8
lists
