124 Equipment installation and configuration
Execute the D C D command for the distant site and compare the
configuration settings at the local and the remote sites. If able to obtain
the distant configuration report and they are both configured correctly, the
MicroLink is up and the communication is established.
To also verify that the communication is established, display the status
at each end of the carrier by executing the D S and D S D commands
on the MMI terminal. If MicroLink is up (carrier is good end-to-end), the
communication across the link is established.
To display local carrier status:
To display remote carrier status:
CRI:: > D S
CRI Remote IPE S/W L1105-A4 Software Version 1.00 8/11/95 10:45
Local Site
In Alarm Status: NO
All Link Maps Normal
Link 0 Alarm Level 0
Link 1 Alarm Level 0
Link 2 Alarm Level 0
CRI::> D S D
Distant End Ready
D S
CRI Remote IPE S/W R1105-B6 Software Version 1.00 8/11/95 10:45
Remote Site
In Alarm Status: NO
All Link Maps Normal
Link 0 Alarm Level 0
Link 1 Alarm Level 0
Link 2 Alarm Level 0
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Display carrier status
Status at the local site
No alarms detected
No link has been spared
Carrier 0 status
Carrier 1 status
Carrier 2 status
Display distant carrier status
Distant end acknowledged
Command received
Status at the remote site
No alarms detected
No link has been spared
Carrier 0 status
Carrier 1 status
Carrier 2 status
