Table 13
NT7R52 Remote Carrier Interface card system monitor address
selection
RCI System
Monitor
Address
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Pull the NT7R52AA Remote Carrier Interface card locking
devices away from the faceplate.
Holding the card by these locking devices, insert it into the card
guides in the card slot marked Cont., which is located to the right
of slot 7. Make sure to use the card guides immediately to the
right of slot 7.
Slide the card into the module until it engages the backplane
connector.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
SW11 Positions 1–5 (1 = ON, 0 = OFF)
1 2 3
0 0 0
0 0 0
0 0 0
0 0 1
0 0 1
0 0 1
0 0 1
0 1 0
0 1 0
0 1 0
0 1 0
0 1 1
0 1 1
0 1 1
0 1 1
1 0 0
1 0 0
1 0 0
1 0 0
1 0 1
1 0 1
1 0 1
1 0 1
1 1 0
1 1 0
1 1 0
1 1 0
1 1 1
1 1 1
1 1 1
1 1 1
4 5
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
