100 Equipment installation and configuration
Procedure 19
Installing Carrier Remote IPE Cabinets
Step
1
2
3
4
5
6
7
8
9
10
11
Action
Unpack and inspect the cabinet.
Level and install the mounting bracket on the wall as shown in
Figure 16 "Carrier Remote IPE cabinet" (page
If installing the expansion cabinet next to the main cabinet,
line up the two brackets and use the provided spacer between
brackets.
Remove the front cover and all cards from the cabinet to make
the cabinet lighter and to prevent card damage in case the
cabinet drops when being installed onto the wall.
Position the cabinet over the mounting bracket so that the
bracket hook engages the slot at the rear of the cabinet.
The slot is located at the top center of the cabinet as shown in
Figure 16 "Carrier Remote IPE cabinet" (page
Bolt the cabinet to the wall by using two wood screws at the
lower front of the cabinet.
See Figure 16 "Carrier Remote IPE cabinet" (page 101)
screw hole locations.
Install the 6 AWG copper ground wire between the approved
building ground and the ground lug at the bottom of the cabinet.
Repeat steps 3 through 6 for the expansion cabinet, if required.
Install the power supply in the Pwr Sup slot in the
NT1P70/NT1P60 main cabinet shelf and turn the power switch
to OFF.
At the building ground end of the wire, use two fastening
clamps to connect the wire to the building ground, insulate the
connection with electric tape, and post a DO NOT DISCONNECT
tag.
Disconnect the building ground wire at the ground lug on the
NT1P70/NT1P60 main cabinet and measure the resistance
between the tip of the disconnected ground wire and the ground
lug on the cabinet.
If the resistance is more than 5 ohms, check the building ground
and the ground terminal at the AC wall outlet where the cabinet
power cord is connected.
For an AC system, connect the NTAK98AA Power Cord from the
IPE shelf NTAK04 AC/DC power supply to the commercial AC
power outlet.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
101).
101).
for
