Table 34
8-pin modular jack pin assignment for all carrier connections (cont'd.)
T1/E1 Carrier Link 8-Pin Modular Jack Pinouts
8-Pin Modular
Jack Signal Name
6
7
8
Note: The cable that connects to this connector is provided in the NT7T87AA
T1 CSU Cable Kit. The cable is a straight through cables between the Carrier
Remote IPE 8-pin modular jack and the Telco demarcation point. If the carrier
links are just hardwired without using Telco network, pins 1 and 2 must be turned
over (swapped) with pins 5 and 4 respectively at one end of the cable.
Table 35
NT7R58AA Maintenance Panel 6-pin modular jack system monitor pin
assignment for J5 and J6 connectors
System Monitor 6-Pin Modular Jack Pinouts
8-Pin Modular
Jack
J5-1
J5-2
J5-3
J5-4
J5-5
J5-6
J6-1
J6-2
J6-3
J6-4
J6-5
J6-6
Note: J5 modular jack provides signals towards the Master system monitor and
J6 modular jack provides signals away from the Master system monitor.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Notice for Canadian installations 203
N/C
N/C
N/C
Signal Name
N/C
XSTXB
XSTXA
XSRXB
XSRXA
N/C
N/C
XMTXB
XMTXA
XMRXB
XMRXA
N/C
Signal Description
No connection
No connection
No connection
Signal Description
No connection
Transmit (NEGATIVE)
Transmit (POSITIVE)
Receive (NEGATIVE)
Receive (POSITIVE)
No connection
No connection
Transmit (NEGATIVE)
Transmit (POSITIVE)
Receive (NEGATIVE)
Receive (POSITIVE)
No connection
