Title page
Nortel Networks Communication Server 1000
Nortel Networks Communication Server 1000 Release 4.0
ISDN Basic Rate Interface
Installation and Configuration
Document Number: 553-3001-218
Document Release: Standard 2.00
Date: September 2004
Year Publish FCC TM
Copyright © 2003—2004 Nortel Networks
All Rights Reserved
Produced in Canada
Information is subject to change without notice. Nortel Networks reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant.
SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Communication Server 1000S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nortel Communication Server 1000S

Summary of Contents for Nortel Communication Server 1000S

  • Page 1 All Rights Reserved Produced in Canada Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
  • Page 3 Page 3 of 120 Revision history September 2004 Standard 2.00. This document is up-issued for Communication Server 1000 Release 4.0. October 2003 Standard 1.00. This document is a new NTP for Succession 3.0. It was created to support a restructuring of the Documentation Library, which resulted in the merging of multiple legacy NTPs.
  • Page 4 Page 4 of 120 Revision history 553-3001-218 Standard 2.00 September 2004...

  • Page 5: Table Of Contents

    Page 5 of 120 Contents About this document ..... . . Subject ..........Applicable systems .
  • Page 6 Page 6 of 120 Contents Preparing the system ..... . . Contents ..........Introduction ..

  • Page 7: About This Document

    Page 7 of 120 About this document Contact your system supplier or your Nortel Networks representative to verify that the hardware and software described are supported in your area. Remember the following: • ISDN Basic Rate Interface (BRI) trunking is not available in North America.

  • Page 8: Applicable Systems

    This NTP contains information about systems, components, and features that are compatible with Nortel Networks Communication Server 1000 Release 4.0 software. For more information on legacy products and releases, click the Technical Documentation link under Support on the Nortel Networks home page: http://www.nortelnetworks.com/...

  • Page 9: Intended Audience

    • Communication Server 1000M and Meridian 1: Large System Upgrade Procedures (553-3021-258) • Communication Server 1000S: Upgrade Procedures (553-3031-258) Intended audience This document is intended for individuals responsible for the planning, engineering, and administration of the applicable system. ISDN Basic Rate Interface...

  • Page 10: Conventions

    Page 10 of 120 About this document Conventions Terminology In this document, the following systems are referred to generically as “system”: • Communication Server 1000S (CS 1000S) • Communication Server 1000M (CS 1000M) • Communication Server 1000E (CS 1000E) • Meridian 1 The following systems are referred to generically as “Small System”:...

  • Page 11: Related Information

    • Communication Server 1000S: Installation and Configuration (553- 3031-210) Online To access Nortel Networks documentation online, click the Technical Documentation link under Support on the Nortel Networks home page: http://www.nortelnetworks.com/ CD-ROM To obtain Nortel Networks documentation on CD-ROM, contact your Nortel Networks customer representative.
  • Page 12 Page 12 of 120 About this document 553-3001-218 Standard 2.00 September 2004...

  • Page 13: Preparing For Installation

    Page 13 of 120 Preparing for installation Contents This section contains information on the following topics: Preparing the site......... . Unpacking and inspecting .

  • Page 14: Unpacking And Inspecting

    Page 14 of 120 Preparing for installation • Wire the building between ISDN BRI terminal locations and the distribution frame. Refer to the “Engineering guidelines” section of ISDN Basic Rate Interface: Features (553-3001-380) for wiring specifications and guidelines. For the location of the terminals and the distribution frame, use the Building Cable Plan developed according to instructions in the “Planning the site”...

  • Page 15: Taking Inventory

    Preparing for installation Page 15 of 120 Taking inventory After unpacking, verify that all the equipment necessary is at the site before installation begins. Check the equipment received against the shipping documents. Note any shortages and report them to your sales representative. ISDN Basic Rate Interface Installation and Configuration...
  • Page 16 Page 16 of 120 Preparing for installation 553-3001-218 Standard 2.00 September 2004...

  • Page 17: Installing Isdn Bri Hardware

    Page 17 of 120 Installing ISDN BRI hardware Contents This section contains information on the following topics: Installing ISDN BRI hardware for line applications....Installing ISDN BRI hardware for trunk applications ... . . Selecting the card slots .
  • Page 18 Page 18 of 120 Installing ISDN BRI hardware Install the Multi-Purpose ISDN Signaling Processors (MISPs). Install the S/T Interface Linecards (SILCs) and/or U Interface Linecards (UILCs) or Basic Rate Signaling Concentrators (BRSCs). Connect ISDN BRI terminals. This procedure comprises the following: —...
  • Page 19 Installing ISDN BRI hardware Page 19 of 120 Table 2 lists the modules that can house ISDN BRI cards. Table 2 ISDN BRI card location SILCs, Supported UILCs, Modules Systems BRSCs MISPs NT4N41 Large Network — Core/Network Module Systems slots NT8D35 81C CPPII Network...
  • Page 20 Page 20 of 120 Installing ISDN BRI hardware • An MISP supports a set of 4 SILCs or UILCs when not supporting a BRSC. • An MISP can support both BRSCs and SILCs or UILCs at the same time. If it serves one BRSC, an MISP can also support three line cards. If it supports two or more BRSCs, an MISP can also support two line cards.
  • Page 21 Installing ISDN BRI hardware Page 21 of 120 Figure 1 shows the NT8D35 Network module. Figure 1 NT8D35 Network module (Large System) CE Module CE Module Network-type cards: NT8D04 Superloop Net QPC414 Network Card NT8D17 Conference/TDS PRI/DTI (5-9) PRI/DTI (5-9) DCHI (5-13) DCHI (5-13) MSDL (5-13)
  • Page 22 Page 22 of 120 Installing ISDN BRI hardware Figure 2 shows the NT8D37 IPE module. Figure 2 NT8D37 IPE module (Large System) PE Module PE Module Intelligent Intelligent line and trunk line and trunk cards cards Cont Cont PE Pwr Sup PE Pwr Sup Rng Gen Rng Gen...
  • Page 23 Installing ISDN BRI hardware Page 23 of 120 Figure 3 shows the NT4N41 Core/Network module. Figure 3 NT4N41 Core/Network module (Large System) Core MMDU cCNI UTIL COM 1 COM 2 LAN 2 LAN 1 INIT RESET ALRM SPKR HDD PWR PS 0 10 11 c9 c10 c11 c12 c13 c14 c15 CP...
  • Page 24 Page 24 of 120 Installing ISDN BRI hardware Repeat steps 1 through 5 for each cover requiring removal. End of Procedure Figure 4 Module cover locking latches Large System Turn to unlock Turn to unlock Slide to Slide to Lock screw unlatch cover unlatch cover Sliding Latch Knob...
  • Page 25 Installing ISDN BRI hardware Page 25 of 120 Push the tabs firmly against the front panel of the card so they latch to the front lip in the module and to the post on the card. Observe the red LED on the MISP faceplate. •...
  • Page 26 Page 26 of 120 Installing ISDN BRI hardware Slide the BRSC, SILC, or UILC into the module until it engages the backplane connector. Push the card firmly into the connector using the locking devices as levers by pushing them toward the card's front panel. Push the tabs firmly against the front panel of the card so they latch to the front lip in the module and to the post on the card.
  • Page 27 Installing ISDN BRI hardware Page 27 of 120 Procedure 7 Connecting ISDN BRI terminals to the system To connect the ISDN BRI terminals to the system, perform the following steps. • Connect the system to the MDF. • Cross-connect the MDF. •...
  • Page 28 Page 28 of 120 Installing ISDN BRI hardware Figure 5 Connect the ISDN BRI terminals to the Large System Main NE-A25B Cable NE-A25B Cable Distribution Meridian 1 Meridian 1 Frame Intermediate Intermediate Distribution Distribution Frames Frames IPE I/O Panel IPE I/O Panel SILC DSL (Office Wiring) Modular Cable Wall Outlets...
  • Page 29 Installing ISDN BRI hardware Page 29 of 120 Procedure 8 Connect the modules to the MDF Modules connect to the MDF using NE-A25B cables with 50-pin D-type male connectors on each end. One end of the cable plugs into the Input/Output (I/O) panel at the rear of the module, and the other end plugs into the MDF.
  • Page 30 Page 30 of 120 Installing ISDN BRI hardware Figure 6 Connect the system to the MDF IPE I/O panel CE/PE I/O panel Large System Meridian 1 J3 G NE-A25B External Communication Cable Main Distribution Frame Rear 553-7697 SILC/UILC port designations at the MDF Table 3 on page 31 and Table 4 on...
  • Page 31 Installing ISDN BRI hardware Page 31 of 120 designation labels for the IPE module. The UILC port designation labels for the IPE and CE modules are shown in Table 4. Table 3 SILC port designations at the MDF: NT8D37 IPE module (16-cable configuration) (Part 1 of 2) T-T+R+R- T-T+R+R-...
  • Page 32 Page 32 of 120 Installing ISDN BRI hardware Table 3 SILC port designations at the MDF: NT8D37 IPE module (16-cable configuration) (Part 2 of 2) T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R- T-T+R+R Note 1: For the SILC port designations shown in this table, substitute Tx- Tx+ Rx+ Rx- for every occurrence of T- T+ R+ R-.
  • Page 33 Installing ISDN BRI hardware Page 33 of 120 Table 4 UILC port designation labels at the MDF: NT8D37 IPE module (16-cable configuration) (Part 2 of 2) Note: The cable pair designated TR is a 2B1Q full-duplex U interface. Cross-connecting the MDF The MDF cross-connects NE-A25B cables connected to SILC and UILC ports with building wiring connected to ISDN BRI terminals.
  • Page 34 Page 34 of 120 Installing ISDN BRI hardware Procedure 9 Cross-connecting SILC and/or UILC ports to the building wiring Perform the following steps to cross-connect the SILC and/or UILC ports to the building wiring. Identify the card type (SILC or UILC) for a connector on the MDF. Refer to the IPE or CE module card location form at the end of this chapter, which shows the card type connected to each I/O panel connector.
  • Page 35 Installing ISDN BRI hardware Page 35 of 120 Figure 7 Cross-connect the SILC port to the office wiring Port 0 Distribution frame (Note 1) Port 1 Port 2 Port 3 Port 4 Cross connect wires or Auxilary Power Source if more that 2 W cable for DS1 Port 0 are required for DSL 1...
  • Page 36 Page 36 of 120 Installing ISDN BRI hardware Figure 8 Cross-connect the UILC port to the office wiring Distribution frame Port 0 Port 1 Port 2 Port 3 Port 4 Cross connect wires or cable for DS1 DSL1 DSL 2 DSL 3 DSL 1 wiring for SILC Port 0...
  • Page 37 Installing ISDN BRI hardware Page 37 of 120 Table 5 shows pair-terminations for connectors. Table 5 NT8D37 IPE module SILC and UILC pair-terminations for connectors A, E, K, R (12-cable configuration) Port signals I/O panel connectors Card SILC UILC Pairs Pair color port 0Tx - / 0Tx +...
  • Page 38 Page 38 of 120 Installing ISDN BRI hardware Table 6 shows pair-terminations for connectors B, F, L, S. Table 6 NT8D37 IPE module SILC and UILC pair-terminations for connectors B, F, L, S (12-cable configuration) Port signals I/O panel connectors Card SILC UILC...
  • Page 39 Installing ISDN BRI hardware Page 39 of 120 Table 7 shows pair-terminations for connectors C, G, M, T. Table 7 NT8D37 IPE module SILC and UILC pair-terminations for connectors C, G, M, T (12-cable configuration) Port signals I/O panel connectors Card SILC UILC...
  • Page 40 Page 40 of 120 Installing ISDN BRI hardware Connecting the ISDN BRI terminals to the DSL ISDN BRI terminals are connected to DSLs using modular cables up to 10 meters (33 feet) long, with RJ-45 plugs on each end. One end of the cable plugs into the terminal, and the other end plugs into the wall outlet.
  • Page 41 Installing ISDN BRI hardware Page 41 of 120 into the RJ-45 jack, and then plug the telephone cable into the terminating resistor. Note: For every port there is one loop with only one terminating resistor per loop. Each loop can support a maximum of eight telephones. ISDN Basic Rate Interface Installation and Configuration...
  • Page 42 Page 42 of 120 Installing ISDN BRI hardware Figure 9 Connect the ISDN BRI terminal to the S/T interface Optional Power Adapter RJ-45 type RJ-45 type plug wall outlet DSL wiring WHT/ORG BLU/WHT WHT/BLU ORG/WHT GRN/WHT WHT/GRN S/T interface Optional Modular cable external power (maximum...
  • Page 43 Installing ISDN BRI hardware Page 43 of 120 Figure 10 Connect the ISDN BRI network termination (NT1) to the U interface RJ-45 type wall outlet RJ - 45 type plug RJ - 45 type plug Modular cable maximum length 10 m U interface Office Wiring power...

  • Page 44: Installing Isdn Bri Hardware For Trunk Applications

    Page 44 of 120 Installing ISDN BRI hardware Installing ISDN BRI hardware for trunk applications This section explains how to install ISDN BRI hardware to support ISDN BRI trunk applications. The system must already be installed and operating according to the instructions in Communication Server 1000M and Meridian 1: Large System Installation and Configuration (553-3021-210) before performing these procedures.

  • Page 45: Installing The Clock Reference On The Silc

    Installing ISDN BRI hardware Page 45 of 120 Installing the clock reference on the SILC The DSL#0 and DSL#1 on an SILC card can be configured as the reference clock source, with DSL#0 being assigned for the primary clock reference and DSL#1 being assigned for the secondary clock reference.
  • Page 46 Page 46 of 120 Installing ISDN BRI hardware Connecting clock reference cables Complete this procedure to connect the ISDN BRI clock reference cables to the Clock Controller. There are three different cables that route clock signals from the IPE back plane to the Clock Controller face plate (as shown in Figure 11 on page 47).
  • Page 47 Installing ISDN BRI hardware Page 47 of 120 Figure 11 Clock reference cable connection NTND71AA - AD NTND70AA IPE I/O panel CE I/O panel IPE shelf CE shelf NTND72AA 553-7702 Clock recovery The SILC is configured in the slave-slave mode when acting as a trunk interface.

  • Page 48: Installing The Silc And The Uilc

    Page 48 of 120 Installing ISDN BRI hardware to the back plane connector pins. These clocks are provided as differential pairs on back plane pins. See Table 9. Table 9 Clocks as differential pairs Differential pairs Pin # Row A Row B Primary +Ref 0A...
  • Page 49 Installing ISDN BRI hardware Page 49 of 120 Figure 12 Connect the network termination to the U interface and to the S/T interface (in TE mode) Distribution Frame Distribution Frame Port 0 Tx+ Rx+ Tx+ Rx+ Tx+ Rx+ Port 0 Port 1 Port 2 Port 1...

  • Page 50: Card Location Forms

    Page 50 of 120 Installing ISDN BRI hardware Card location forms Use the following card location forms when installing SILC/UILC and BRSC cards. Table 10 Card location form: NT8D37 IPE module (16-cable configuration) IPE Module Card type IPE Module slot I/O panel SILC/UILC/BRSC (SILC/UILC/BRSC)
  • Page 51 Installing ISDN BRI hardware Page 51 of 120 Table 11 Card location form: NT8D37 IPE module (12-cable configuration) Card Type IPE Module IPE module I/O panel SILC/UILC or BRSC (SILC/UILC or BRSC) number slot number connector ports 0–7 0–7 0–3 4–7 0–7 0–7...
  • Page 52 Page 52 of 120 Installing ISDN BRI hardware 553-3001-218 Standard 2.00 September 2004...

  • Page 53: Configuring Isdn Bri Hardware

    Page 53 of 120 Configuring ISDN BRI hardware Contents This section contains information on the following topics: Hardware requirements ........Line and packet data applications.

  • Page 54: Line And Packet Data Applications

    Page 54 of 120 Configuring ISDN BRI hardware Line and packet data applications Table 12 lists the hardware required to configure line and packet data on the system. Table 12 Hardware requirements for line and packet data applications (Part 1 of 2) Hardware Product code Description...

  • Page 55: Isdn Bri Trunking

    ISDN Terminal Adapter provides a connection to an analog telephone and supports circuit-switched or packet data; supports B-channel and D-channel packet data. Any other terminal deemed compatible by Nortel Networks. Terminal adapters Required if connecting non-BRI terminals to the ISDN BRI line interface.
  • Page 56 Page 56 of 120 Configuring ISDN BRI hardware Table 13 Hardware requirements for ISDN BRI trunking Hardware Product code Description MISP circuit card NTBK22 The MISP card (NTBK22) is specific to Small Systems and CS 1000S systems.It performs Data Link (Layer 2) and Network (Layer 3) processing associated with the OSI protocol.

  • Page 57: Cabinets Or Mg 1000S Systems

    Configuring ISDN BRI hardware Page 57 of 120 Configuring ISDN BRI trunking with IP expansion cabinets or MG 1000S systems Configure the MISP card slot number for ISDN BRI trunking in LD 27. Refer to Table 14 for the correct response to the LOOP prompt. Configure DSL for ISDN BRI trunking in LD 27.
  • Page 58 Page 58 of 120 Configuring ISDN BRI hardware Before beginning the procedures, ensure the system is installed and operational. Perform the procedures in the order shown. Select the card slots. See Procedure 13 on page Remove the MISP, if previously installed. See Procedure 15 on page Install the clock controller on the MISP (for trunking applications only).

  • Page 59: Installation Procedures

    Configuring ISDN BRI hardware Page 59 of 120 Initialize a Nortel Networks M5317TDX terminal. See Procedure 23 on page Connect the ISDN BRI trunks for trunking applications: Connect the system cables to the cross-connect terminal. See Procedure 24 on page ii.
  • Page 60 Page 60 of 120 Configuring ISDN BRI hardware Table 15 Small System shelf slot assignments for ISDN BRI cards (Part 2 of 2) ISDN BRI Card MISP SILC is not SILC is clock (see Note 2) clock reference reference UILC Call Server MG 1000S 1 11-14...
  • Page 61 Configuring ISDN BRI hardware Page 61 of 120 Insert the MISP into the selected card slot and lock it in place. Observe the behavior of the LED on the faceplate of the MISP to determine its status: • The LED lights, flashes three times and then stays lit – the MISP is operating correctly but is not configured and enabled.
  • Page 62 Page 62 of 120 Configuring ISDN BRI hardware Use the following guidelines when installing the clock controller on the MISP: • If the primary reference clock source comes from a PRI or DTI, then the clock controller is a daughterboard on the DTI/PRI card. •...
  • Page 63 Configuring ISDN BRI hardware Page 63 of 120 Figure 13 SILC line power options Jumper plug location NT6D70 SILC DSL Port 0 DSL Port 1 Faceplate DSL Port 2 DSL Port 3 J2 (not used) Backplane Storage for connector unused DSL Port 4 jumper plugs DSL Port 5...
  • Page 64 Page 64 of 120 Configuring ISDN BRI hardware Figure 14 Jumper plug settings for normal power on the TX and RX leads BRTN Jumper plugs 553-7580.EPS • Reverse power on the TX and RX leads. This option is used only in Japan and provides power (-48V or -40V) on the RX lead and battery return (BRTN) on the TX lead to power the terminal.
  • Page 65 Configuring ISDN BRI hardware Page 65 of 120 Figure 15 Jumper plug settings for reverse power on the TX and RX leads Jumper plugs BRTN RX TX PWR 553-7581.EPS • No power on the TX and RX leads. This option applies when the terminal is powered locally with an adapter provided with the terminal.
  • Page 66 Page 66 of 120 Configuring ISDN BRI hardware Procedure 17 Removing the SILC and UILC Hold the card by its card-locking devices. Squeeze the tabs to unlatch the card-locking devices and lift them away from the card. Carefully disengage the SILC or UILC from the backplane connector, and slowly slide the card from the cabinet or MG 1000S.
  • Page 67 Configuring ISDN BRI hardware Page 67 of 120 Figure 16 Connecting ISDN BRI terminals to the system Main cross-connect terminal Interemediate cross-connect terminal NE-A25B Cable SILC DSL (Office Wiring) To connector panel Modular Cable Terminating Wall Outlets Resistor AO378866 553-7582.EPS ISDN Basic Rate Interface Installation and Configuration...
  • Page 68 Page 68 of 120 Configuring ISDN BRI hardware Procedure 19 Connecting system cables to the cross-connect terminal Each card slot equipped with a SILC or UILC requires one NE-A25B 25-pair connector cable. Remove the connector retaining bar from the connector panel in the lower part of each cabinet.
  • Page 69 Configuring ISDN BRI hardware Page 69 of 120 Figure 17 Cable connectors in main cabinet INTER J1 J2 J4 J5 J6 J7 J8 J9 J10 Grooves to route cables Retaining Connector retaining bar bar release (remove to install cables) NE-A25B cable to cross-connect terminal 553-7809.EPS Figure 18...
  • Page 70 Page 70 of 120 Configuring ISDN BRI hardware Figure 19 Cable connectors in the second expansion cabinet INTER J21 J22 J24 J25J26J27J28 J29 J30 Grooves to route cables Retaining Connector retaining bar bar release (remove to install cables) NE-A25B cable to cross-connect terminal 553-7811.EPS Figure 20...
  • Page 71 Configuring ISDN BRI hardware Page 71 of 120 Figure 21 SILC port designation label at the cross-connect terminal TX-TX+RX+ TX-TX+RX+ TX-TX+RX+ TX-TX+RX+ TX-TX+RX+ TX-TX+RX+ TX+RX+ RX-0 Note: The pair designated TX- TX+ is the transmit pair. The pair designated RX- RX+ is the receive pair. A SILC port supplies 2 W of power at -48 V (-40 V for Europe), simplexed over the transmit and receive pairs.
  • Page 72 Page 72 of 120 Configuring ISDN BRI hardware Procedure 20 Cross-connecting the DSLs at the cross-connect terminal To cross-connect SILC and/or UILC ports to the building wiring: Identify the card type (SILC or UILC) at the cross-connect terminal. Identify the transmit and receive connections for the SILC and the TIP and RING connections for the UILC from the label of the distribution strip.
  • Page 73 Configuring ISDN BRI hardware Page 73 of 120 Table 16 SILC and UILC port assignments connectors at cross-connect terminal (Part 2 of 2) Connector pin number Wire SILC port UILC port and wire color signals signals color code codes Card ports 2 TX- 2 TX+ 2 RX-...
  • Page 74 Page 74 of 120 Configuring ISDN BRI hardware Figure 23 Cross-connecting a SILC port to the office wiring Cross connect terminal T- T+ R+ R- T- T+ R+ R- T- T+ R+ R- T- T+ R+ R- T- T+ R+ R- Por t 0 Por t 0 Port 1...
  • Page 75 Configuring ISDN BRI hardware Page 75 of 120 Figure 24 Cross-connecting a UILC port to the office wiring Cross connect terminal Port 1 Port 1 Port 2 Port 3 Port 4 Cross connect wires or cable for DS1 10 11 12 13 14 15 16 17 18 19 20 DSL 2 DSL 3 Port 0...
  • Page 76 NUMERIS • ANSI standards Contact your Nortel Networks representative for the latest list of compatible terminals. To connect 1TR6 terminals, an ETSI NET-3 to 1TR6 protocol converter is required. A terminal adapter (the S o -Adapter) has been specifically designed to interface with the ISDN BRI DSL and the 1TR6 terminals.
  • Page 77 Configuring ISDN BRI hardware Page 77 of 120 Table 17 shows the connector pin assignment for the jack and the plug. It also shows the signal names for each interface pin at the SILC and at the terminal. Table 17 S/T interface connector specification RJ45 jack SILC...
  • Page 78 Page 78 of 120 Configuring ISDN BRI hardware The connector pin assignments for the jack and the plug are shown in Table 18. The table also shows signal names for each interface pin at the UILC and at the terminal. Table 18 U interface connector specification RJ45 jack...
  • Page 79 Configuring ISDN BRI hardware Page 79 of 120 Enter the Static TEI at the terminal. Note: Do not perform this step to assign Dynamic TEIs since they are automatically assigned. Enter the Service Profile ID number at the terminal. For detailed information about this procedure, refer to the terminal user guide.
  • Page 80 Page 80 of 120 Configuring ISDN BRI hardware Figure 25 Connecting the ISDN BRI terminal to the S/T interface Optional Power Adapter RJ-45 type RJ-45 type plug wall outlet DSL wiring WHT/ORG BLU/WHT WHT/BLU ORG/WHT GRN/WHT WHT/GRN S/T interface Optional Modular cable external power (maximum...
  • Page 81 Configuring ISDN BRI hardware Page 81 of 120 Figure 26 Connecting the ISDN network terminator to the U interface RJ-45 type wall outlet RJ - 45 type plug RJ - 45 type plug Modular cable maximum length 10 m U interface Office Wiring power source...
  • Page 82 Configuring ISDN BRI hardware Non-BRI terminals The M5000 is Nortel Networks's Universal Terminal Adapter (UTA). It adapts a non-BRI data terminal or an analog (500/2500-type) telephone to the ISDN BRI protocol. Attach a terminal to the M5000 terminal adapter to initialize it.
  • Page 83 Configuring ISDN BRI hardware Page 83 of 120 18 Press DIALPLN until NATIONAL displays. 19 Press EXIT. 20 Press NO to execute SPM. 21 Press YES to enter datafill. 22 Press YES to delete existing datafill. 23 Press KEY# then use to keypad to enter the key number you want to program.
  • Page 84 Page 84 of 120 Configuring ISDN BRI hardware Table 19 M5317TDX terminal error codes (Part 2 of 2) Error Code Number Description >>28<< Voice link not established. >>29<< Circuit data link not established. >>2A<< X25 link not established. >>2B<< No Layer 2 link established. >>30<<...
  • Page 85 Configuring ISDN BRI hardware Page 85 of 120 Procedure 24 Connecting the system cables to the cross-connect terminal Each card slot equipped with an SILC or UILC requires one NE-A25B 25-pair connector cable. The cables connect to the connectors at the bottom of the cabinet or at the rear of the MG 1000S.
  • Page 86 Page 86 of 120 Configuring ISDN BRI hardware page 88. The DSLs are not polarity-sensitive and it is not necessary to maintain signal polarity along each loop. Procedure 25 Cross-connecting DSLs at the cross-connect terminal To cross-connect SILC and/or UILC ports to the trunk wiring facilities: Identify the card type (SILC or UILC) at the cross-connect terminal.
  • Page 87 Configuring ISDN BRI hardware Page 87 of 120 Figure 27 Cross-connecting an SILC port Cross connect terminal Port 0 Port 1 Tx- Tx+ Rx+ Rx- Tx- Tx+ Rx+ Rx- Tx- Tx+ Rx+ Rx- Tx- Tx+ Rx+ Rx- Tx- Tx+ Rx+ Rx- P ort 0 Port 1 Port 2...
  • Page 88 Page 88 of 120 Configuring ISDN BRI hardware Figure 28 Cross-connecting a UILC port Cross connect terminal Port 0 Port 1 Port 0 Port 1 Port 2 Port 3 Port 4 Port 2 Port 3 Cross connect wires or Port 4 cable for DSL 1 Port 5 Port 6...
  • Page 89 Configuring ISDN BRI hardware Page 89 of 120 Figure 29 Connecting the ISDN network terminator to the U interface and to the S/T interface (in TE mode) Cross connect terminal Cross connect terminal Port 0 Tx+ Rx+ Tx+ Rx+ Tx+ Rx+ Port 0 Port 1 Port 2...
  • Page 90 Page 90 of 120 Configuring ISDN BRI hardware 553-3001-218 Standard 2.00 September 2004...

  • Page 91: Preparing The System

    Page 91 of 120 Preparing the system Contents This section contains information on the following topics: Introduction ..........Verifying ISDN BRI operation .

  • Page 92: Setting Up Isdn Bri Test Terminals And Trunks

    Page 92 of 120 Preparing the system • Check the red LED located on the BRSC faceplate. If the red LED is extinguished, check that the BRSC is enabled and operating correctly. If the red LED is lit, check that the BRSC is manually disabled or faulty. To enable a BRSC or to correct a problem, refer to ISDN Basic Rate Interface: Maintenance (553-3001-518).
  • Page 93 Preparing the system Page 93 of 120 Note: Packet data testing can be conducted only if an external packet handler or an Meridian Packet Handler (MPH) is installed as part of the customer configuration, and is supported by the system (like the external DPN-100 packet handler).
  • Page 94 Page 94 of 120 Preparing the system Figure 30 ISDN BRI acceptance testing setup for terminals System Memory CPU Bus Network Bus Superloop MISP MISP Network Network Card Card BRIL S/T Interface Controller Card SILC Terminating resistor Peripheral Bus S/T Interface BRSC SILC UILC...
  • Page 95 Preparing the system Page 95 of 120 Set up ISDN BRI trunking - Local Exchange connectivity Figure 31 on page 96 illustrates a typical configuration to test ISDN BRI Local Exchange connectivity. The ISDN BRI Local Exchange DSL is connected to a Network Termination (NT1) device, which is physically located on the same premises as the system.
  • Page 96 Page 96 of 120 Preparing the system Figure 31 ISDN BRI acceptance testing setup for trunking – Local Exchange connectivity Non ISDN BRI device such as 2500 or digital type telephone Non ISDN BRI Line Card ISDN BRI terminal equipment SILC Central Office...
  • Page 97 Preparing the system Page 97 of 120 Figure 32 ISDN BRI acceptance testing setup for trunking – TIE trunk connectivity Non ISDN BRI device Non ISDN BRI device such as 2500 or such as 2500 or digital type telephone digital type telephone Non ISDN Non ISDN BRI Line Card...
  • Page 98 Page 98 of 120 Preparing the system 553-3001-218 Standard 2.00 September 2004...

  • Page 99: Testing Isdn Bri Functions

    Page 99 of 120 Testing ISDN BRI functions Contents This section contains information on the following topics: Introduction ..........Voice calls .

  • Page 100: Voice Calls

    Page 100 of 120 Testing ISDN BRI functions The tests are divided into: • voice calls • circuit-switched data calls • B-channel and D-channel packet data calls, using an external packet handler and an MPH • ISDN BRI trunk Voice calls A voice call can be established between two voice terminals across a network (ISDN or non-ISDN), between two terminals on the same system, and between two terminals on the same DSL.

  • Page 101: Call Waiting

    Testing ISDN BRI functions Page 101 of 120 Procedure 27 Performing a call hold test From an ISDN BRI terminal, dial an ISDN BRI or a non-ISDN BRI terminal and establish an active call connection. Verify that voice transmission is established by talking with the person at the other terminal.
  • Page 102 Page 102 of 120 Testing ISDN BRI functions Call Waiting is activated only if Hunting is not enabled or fails to handle the incoming call. The incoming call may originate from an ISDN BRI or a non-ISDN BRI terminal. Note: The following test requires that the terminal receiving the second (call waiting) call has multiple DN appearances.

  • Page 103: Call Forward No Answer

    Testing ISDN BRI functions Page 103 of 120 Call Forward No Answer Call Forward No Answer and Second Level Forward No Answer forwards an unanswered call to a Call Forward No Answer Directory Number (DN) after a predetermined number of rings. This feature is enabled at the TSP level when defining the ISDN BRI DN.

  • Page 104: Calling Line Identification Presentation And Restriction

    Page 104 of 120 Testing ISDN BRI functions Verify the call was forwarded to the attendant by answering the call at the attendant console. The attendant console will display the call-originating identification number and the notification of call redirection. Hang up at the call-originating ISDN BRI terminal to release the call connection.

  • Page 105: Isdn Bri Conference (National Isdn-1 And Etsi)

    Testing ISDN BRI functions Page 105 of 120 Set PRES = NO in the TSP data block for the calling party ISDN BRI terminal. If the calling party ISDN BRI terminal has an option on the set to allow or restrict the presentation of the calling party number, select the option to allow presentation and place a call to another ISDN BRI terminal.
  • Page 106 Page 106 of 120 Testing ISDN BRI functions On the ISDN BRI terminal, configure Conference. This procedure largely depends on the implementation of feature key management on individual terminals. In general: a) The terminal provides Conference as a selectable feature to be programmed on a hard/soft key.

  • Page 107: Isdn Bri Special Hunting

    Testing ISDN BRI functions Page 107 of 120 nnn = feature indication ID (0 - 127) (If nnn is not entered, it is assumed to be the same as mmm) On the ISDN BRI terminal, if the signaling type/protocol is configurable, then select National ISDN-1or ETSI protocol.
  • Page 108 Page 108 of 120 Testing ISDN BRI functions or until the maximum number of hunt steps is exhausted. Use LD 27 to define the hunting DNs in the DSL. See “DSL configuration procedures” in ISDN Basic Rate Interface: Features (553-3001-380). Special hunting for ISDN BRI supports calls terminating at an ISDN BRI terminal.

  • Page 109: Isdn Bri National Isdn-1 Call Forward All Calls

    Testing ISDN BRI functions Page 109 of 120 Place a voice call to one of the busy ISDN BRI terminals with hunting enabled. Since the channel type required to handle the incoming call type is busy, hunting is automatically invoked to find an idle DN in the hunting chain.

  • Page 110: Isdn Bri Etsi Call Forwarding Unconditional

    Page 110 of 120 Testing ISDN BRI functions Procedure 34 Perform an ISDN BRI NI-1 Call Forward All Calls test The following is to test the forwarding of a voice call from an ISDN BRI M5317 set. Set up ISDN BRI NI-1 Call Forward All Calls in LD 27 (refer to the “Configuring ISDN BRI features”...
  • Page 111 Testing ISDN BRI functions Page 111 of 120 An ISDN BRI user can assign the same address or a different address for voice or data calls being forwarded. Calls can also be forwarded to an ISDN BRI terminal or a non-ISDN BRI terminal. When the CFU feature is activated, outgoing calls can still be made from the ISDN BRI terminal.

  • Page 112: Circuit-Switched Data Calls

    Page 112 of 120 Testing ISDN BRI functions From the second DN, place a call to the first DN, to verify that the call ha been forwarded. To cancel ISDN BRI ETSI Call Forwarding Unconditional: Press the Forward or the Cancel key. Circuit-switched data calls A circuit-switched data call can be established between two data terminals over a B-channel.

  • Page 113: Packet Data Transmission

    Testing ISDN BRI functions Page 113 of 120 Verify that the transmitted data has been received successfully by checking transmitted information for accuracy. Read the information on the screen or print it on the local printer. Release the connection. Packet data transmission A packet data call can be established between two data terminals over a B-channel or a D-channel.
  • Page 114 Page 114 of 120 Testing ISDN BRI functions See ISDN Basic Rate Interface: Features (553-3001-380) for a detailed description of how to configure relevant ISDN BRI packet data transmission parameters in LD 17, LD 16, and LD 14. Procedure 37 Perform a B-channel packet data transmission test using an external packet handler From an ISDN BRI B-channel packet data terminal, dial another local or...
  • Page 115 Testing ISDN BRI functions Page 115 of 120 Procedure 39 Perform a D-channel Switched Virtual Circuit packet data transmission test using an MPH From an ISDN BRI D-channel packet data terminal, dial another local ISDN BRI packet data terminal or a remote packet data terminal (depending on how you have configured your MPH application).

  • Page 116: Testing An Isdn Bri Trunk

    Page 116 of 120 Testing ISDN BRI functions Procedure 40 Perform a B-channel Switched Virtual Circuit packet data transmission test using an MPH From an ISDN BRI B-channel packet data terminal, dial the Network Terminal Numbers (NTNs) as configured in LD 27. Establish an active call connection.

  • Page 117: Generating Traffic Reports

    Page 117 of 120 Generating traffic reports Contents This section contains information on the following topics: Introduction ..........Introduction This chapter describes how to generate traffic reports to verify that the traffic generated during voice and data transmission testing has been stored by the...
  • Page 118 Page 118 of 120 Generating traffic reports ISDN BRI MISP and/or BRSC messages report Trunk DSL system traffic report MPH traffic report For example, to verify ISDN BRI traffic generated during acceptance testing, select the network traffic report and the MISP traffic report as follows: INVS 1 11 The system printer should print these two reports.
  • Page 119 Generating traffic reports Page 119 of 120 Figure 33 Network traffic report TERM 00000 0000200 00093 00000 0000980 00800 TERM 00000 0000005 00030 00000 0000039 00034 CONF 00000 0000030 00040 00000 0000090 00080 TERM 00000 0000080 00030 00000 0000235 00230 TERM 00000 0000070...
  • Page 120 Page 120 of 120 Generating traffic reports 553-3001-218 Standard 2.00 September 2004...
  • Page 122 Copyright © 2003—2004 Nortel Networks All Rights Reserved Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
