Table 3
Remote Carrier IPE module hardware list (cont'd.)
Component
NT7R68AA Remote
Carrier/Alarm Cable
Assy
NT7R68BA Remote
Maintenance Cable
Assy
NT7R67EA Coaxial
Interface Adapter
Cable
NT7R86AA Auxiliary
Alarm Cable Assy
NT7R87AA T1 CSU
Cable Kit
NT8D46AL System
Monitor Serial Link
Cable
Table 4 "Carrier Remote IPE wall-mounted cabinet hardware list" (page
16) lists the Carrier Remote IPE cabinet equipment.
and external connectors pin assignment" (page 197)
connectors pin assignments.
Description
This cable assembly connects the Remote Carrier Interface to the I/O
panel at the rear of the IPE module for T1/E1 and auxiliary customer
alarm connections. Consists of the NT7R68HA cable with 24-pin
block P1 connector that plugs into the IPE backplane connector, the
NT7R59AA Carrier Panel assembly already connected to the cable
with P2 DB-15HD male connector, and the NT7R60AA Carrier/ Alarm
Panel assembly connected to the cable with P3 DB-9 female connector.
The NT7R59AA Carrier Panel assembly provides two 8-pin modular
carrier jacks and the NT7R60AA Carrier/Alarm Panel assembly provides
one 8-pin modular carrier jack and one DB-15 female alarm connector.
Refer to Appendix C, Figure 28 "Remote Carrier IPE module connection
diagram (single RCI configuration)" (page
This cable assembly connects the Remote Carrier Interface to the
I/O panel at the rear of the IPE module for system monitor and MMI
connections. Consists of the NT7R68GA cable with 24-pin block P1
connector that plugs into the IPE connector on the backplane, the
NT7R61AA Maintenance Panel assembly already connected to the cable
with P2 DB-15 male cable connector. The NT7R61AA Maintenance
Panel assembly provides one 6-pin modular jack for system monitor
and one DB-9 male MMI port connector. Refer to Appendix C,
28 "Remote Carrier IPE module connection diagram (single RCI
configuration)" (page 200).
Cable with one 8-pin modular plug that plugs into the NT7R68AA Remote
Carrier/Alarm Panel Assy 8-pin modular jack and two BNC connectors
that plug into the carrier link BNC connectors.
Connects auxiliary alarms, such as customer external alarms, to the
DB-15HD female Alarm connector on the NT7R60AA Carrier/Alarm
Panel. The cable is 9.75 m 32 feet long.
This cable kit consists of a DB-15M/RJ-48 adapters and a 9.75 m (32
ft) RJ-48 to RJ-48 cable. The appropriate adapter is used to connect to
a CSU and the cable is used to connect the adapter to the NT7R59AA
Carrier Panel Assy and the NT7R60AA Carrier/Alarm Panel Assy RJ-48
connector.
Connects the 6-pin modular jack J5 on the NT7R61AA Maintenance
Panel assembly to the J6 system monitor jack in the pedestal.
