156 Carrier Remote IPE maintenance
Table 28
Keyboard to keypad translation table (cont'd.)
To use a diagnostic program on the system. follow the steps in
36 "Using a diagnostic program on the system" (page
Procedure 36
Using a diagnostic program on the system
Step
1
2
3
4
5
Terminal keyboard
M N
P R
T U
W X
Action
Press the prime DN key.
Place the telephone in the maintenance mode by entering
xxxx91 on the keypad, where xxxx is the customer's special
prefix number (SPRE) as defined in LD 15.
Normally xxxx is 1, therefore 191 would be entered.
Enter ** to check if the communication link is idle.
a If a busy tone is detected, the system is in session with
another maintenance or administration terminal. Enter ****
to force the other terminal to log out.
b If a busy tone is not detected, the system is idle and the
system is automatically accessed.
Enter 53#xx## to load a diagnostic program, where xx is the
program number.
For example, to load Network and IPE Diagnostic Program LD
32, enter 53#32##.
Perform the maintenance tasks by executing the maintenance
commands resident in the loaded program.
For example, from Network and IPE Diagnostic Program LD 32,
a network loop can be disabled by executing DISL loop, where
loop is the Local Carrier Interface card loop; for example, 3. To
execute this command enter 3475#3## on the keypad.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
O 6
7
S
V 8
Y 9
0
Space or #
Return
156).
Telephone key pad
6
7
8
9
0
#
##
Procedure
