110 Equipment installation and configuration
These cables have already been connected to the MDF in the
preinstallation preparation phase according to the instructions in "Cabling
lines and trunks" in Communication Server 1000M and Meridian 1 Large
System Installation and Commissioning (NN43021-310) ().
Procedure 25
Connecting subscriber loop (tip and ring) cables to the cabinet 50-pin
connectors
Step
1
2
3
4
5
Auxiliary alarm connections
To connect the auxiliary or external alarm indicators to the NT7R60AA
Carrier/Alarm Panel assembly connector, use the NT7R86AA Auxiliary
Alarm Cable assembly. Follow the steps in
auxiliary or external alarm indicators" (page
Procedure 26
Connecting the auxiliary or external alarm indicators
Step
1
Action
Remove the locking bar from connectors designated J1 through
J10.
Install the 50-pin connector terminating the MDF cable marked
J1 and plug it into the connector at the bottom of the cabinet also
designated J1.
Repeat step 2 for the remaining MDF cables from J2 through J10
for card slot 1 through 9.
If the expansion cabinet is also installed, identify the 50-pin
connectors terminating the MDF cable designated J11 through
J16 and plug them into their respective connectors at the bottom
of the cabinet also designated J11 through J16 for card slots 10
through 15.
Replace the locking bar(s) in the cabinet(s) over the cable
connectors.
Action
Plug the NT7R86AA Auxiliary Alarm Cable assembly DB-15HD
male cable connector into the DB-15HD female connector on the
NT7R60AA Carrier/Alarm Panel assembly.
The DB-15HD connector pin assignment is shown in Appendix
C, Table 38 "NT7R60AA Carrier/Alarm Panel DB-15 HD alarm
connector pin assignment for Carrier Remote IPE module" (page
205).
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
--End--
Procedure 26 "Connecting the
110).
