Connecting multiple Local Carrier Interface cards to the SDI
card
Refer to
daisy-chain connection)" (page 199)
connector. If it is necessary to change the gender at the
terminal, use the appropriate compact gender changer.
MMI terminal connection using a modem:
•
If using a modem to connect a distant MMI terminal to
the MMI port on the local I/O panel, plug the DB-9 female
connector of the NT7R66BA MMI Cable into the P3 DB-9
male connector of the NT7R67DA cable.
•
Plug the DB-25 male end of the NT7R66BA MMI Cable into a
DB-25F/DB-25M nullmodem.
•
Connect the nullmodem DB-25 male connector to the modem
DB-25 female connector.
MMI terminal connection using an A/B switch box:
•
Connect the P3 of the NT7R67DA Local External
Maintenance Cable assembly DB-9 male connector into the
DB-9 female connector of the NT7R66BA MMI Cable.
•
Plug the DB-25 male and of the NT7R66BA MMI Cable into
the A/B switch box DB-25 female C connector.
•
From the switch box, a local MMI terminal can be connected
directly to the A position on the switch box using a standard
DB-25M/DB-25M straight-through cable.
•
As well, a distant MMI terminal can be connected over
a standard DB-25M/DB-25M straight-through cable, a
nullmodem, and a modem to the switch box B position.
Terminal/Modem connections over the MSDL Single Terminal
Access:
•
To avoid using the A/B switch box, use three ports on the
MSDL card.
•
Connect one MSDL port to the local MMI terminal.
•
Connect the second MSDL port to a modem.
•
Connect the third MSDL port to the P3 DB-9 male connector
of the NT7R67DA Local External Maintenance Cable
assembly by using the NT7R66BA MMI Cable.
Figure 27 "Multiple LCIs connection diagram (local site
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
--End--
to see the SDI connection diagram.
