184 Carrier Remote IPE maintenance
Procedure 47
Removing and replacing a Remote Carrier Interface card
Step
1
2
3
4
5
6
7
8
9
Action
Log in on the maintenance terminal as described in
system maintenance programs" (page
At the > prompt, type LD 32 and press the Enter key to access
the program.
Type DSXP x, where x is the Remote Carrier Interface card
number, and press the Enter key to disable the card.
The Remote Carrier Interface card is now disabled and can be
removed.
Unlatch the card locking devices by squeezing the tabs and
pulling them away from the card.
Pull the card out of the IPE module or cabinet and place it into
an antistatic bag away from the work area.
Hold the replacement card by the card locking devices and insert
it partially into the card guides in the module.
Pull the upper and lower locking devices away from the faceplate
on the card and insert the card firmly into the backplane
connector.
Press the card locking devices firmly against the faceplate to
latch the card inside the module. The Remote Carrier Interface
card automatically starts the self-test.
Observe the red LED on the front panel during the self-test.
If it flashes three times and stays on, it has passed the test. Go
to step 9.
If it does not flash three times and then stays on, it has failed the
test. Pull the card partially out of the module and reinsert it firmly
into the module.
If the problem persists, troubleshoot or replace the Remote
Carrier Interface card.
At the . prompt (dot prompt) in the LD 32 program, type ENXP x
(v), where x is the Remote Carrier Interface card number and
v is the loadware version that can be optionally downloaded
after the enabling process, and press the Enter key to enable the
card.
If the uppermost red LED on the Remote Carrier Interface
card faceplate turns off, the card is functioning correctly and
is enabled. The outcome of the self-test is indicated by LD 32
on the MMI terminal connected to the Remote Carrier Interface
card.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
"Using
154).
