Nortel Communication Server 100 Manual page 93

configuration)" (page
in Procedure 15 "Installing the NT7R68BA Remote Maintenance Cable
Assembly" (page 93).
Procedure 15
Installing the NT7R68BA Remote Maintenance Cable Assembly
Step Action
1 Identify the empty connector cutout that is the appropriate size
for the NT7R61AA Maintenance Panel assembly.
Refer to "Carrier Remote IPE Module I/O panel connector
selection" (page 61)
recommendation.
2 Install the NT7R61AA Maintenance Panel assembly into the
recommended J2 connector cutout on the I/O panel. Tighten the
retaining screw.
3 Plug the P1 24-pin connector of the NT7R68BA Remote
Maintenance Cable assembly into the SL0 connector on the IPE
Module's backplane.
shows the rear of the Carrier Remote IPE module and cables connecting
the backplane connectors to the module's I/O panel assembly connectors
installed into the recommended connector cutouts.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Carrier Remote IPE column installation 93
200). To install the panel assembly, follow the steps
or connector cutouts selection
--End--
