Local and Remote Carrier Interface cards system maintenance
commands
Local Carrier Interface card and Remote Carrier Interface card
maintenance commands are identical to the standard NT8D04 Superloop
Network and NT8D01 Peripheral Controller cards. These commands are
used to manipulate the operational status and perform diagnostic tests on
these cards. These commands are located in Network and IPE Diagnostic
LD 32, which can be accessed using the administration terminal or the
maintenance telephone.
Table 25 "System carrier superloop maintenance commands" (page
151)
Network and IPE Diagnostic LD 32. The full list of LD 32 commands is
described in the Software Input Output Administration (NN43001-611)
(). Detailed output of maintenance commands is explained in various
maintenance procedures in this chapter.
Table 25
System carrier superloop maintenance commands
Command
DISL sl
ENLL sl
STAT sl
IDC sl
XPEC
SUPL
lists carrier-related superloop maintenance commands provided by
Response
Prompt
OK and prompt
listing and prompt
LCRI VERS=xxx
FW IS SANE
aaaaaaaaaaa
XPEC VERS=xxx FW
IS SANE
aaaaaaaaaaa
nn
nnn
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Description
Disables a specific superloop
Enables a specific superloop
Displays status for one or all network loops.
Shows carrier alarm status, number of idle
time slots per carrier, type of carrier (T1/E1),
No-New-Data status, and sparing status
Displays the Local Carrier Interface card ID,
the superloop number, and the corresponding
Remote Carrier Interface card ID
Local Carrier Interface card
xxx= loadware version
Content of the LCI card ID in the EEPROM.
Remote Carrier Interface card
xxx= loadware version
Content of the RCI card ID in the EEPROM
Maps RCI (Peripheral Controller) to LCI (carrier
superloop) and shows software status of the
RCI (Peripheral Controller)
Maps LCI (carrier superloop) to RCI (Peripheral
Controller)
Diagnostic tools 151
