Procedure 22
Installing cards into the Carrier Remote IPE cabinet
Step Action
1 Set the DIP switches on the NT7R52 Remote Carrier Interface
card to specify the carrier type (T1 or E1), the distance to the
first repeater, the terminal characteristics, and the system
monitor address emulation.
The DIP switch setting depends on the physical system
configuration.
Note: Figure 14 "Remote Carrier Interface card DIP-switch
locations and functions" (page
the DIP switches and their functions. Switches 2, 3, and 4
determine if carrier 0 is a T1 or an E1 link, switches 4, 6, and
7 determine if carrier 1 is a T1 or an E1 link, and switches 8,
9, and 10 determine if carrier 2 (spare carrier) is a T1 of an
E1 link. All three carrier links must be of the same type, that
is, T1 or E1. Switches 2 through 10 are not read by firmware.
Switches 1 and 11 define parameter listed in the table of
Figure 14 "Remote Carrier Interface card DIP-switch locations
and functions" (page
to ON to indicate remote site. Switches 1 and 11 are read
by firmware.
2 Pull the Remote Carrier Interface card locking devices away from
the faceplate and, holding the card by these devices, insert the
card into the card guides in slot Cont.
Refer to Figure 16 "Carrier Remote IPE cabinet" (page 101)
card slot positions in the shelf.
3 Slide the card into the cabinet until it engages the backplane
connector and then push the locking device levers toward
the faceplate to insert the card connector into the backplane
connector and lock the card in place.
4 Observe the LED on the card as it performs self-tests.
The LED should blink three times and then stay lit until the
Remote Carrier Interface card is enabled by software. When
enabled by software, the LED turns off permanently, if the card
is operational.
5 Install IPE cards in slots 0 through 9 by pulling the card locking
devices away from the faceplate, inserting the cards into the
card guides, engaging the backplane connector, and locking the
card in place by pressing the locking devices against the card
faceplate.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Carrier Remote IPE cabinet installation 105
89), shows the location of
89). Verify that SW1 position 2 is set
for
